6m Platform Small Scissor Lift , Lightweight Scissor Lift Equipment GTJZ06
6m Platform Small Scissor Lift , Lightweight Scissor Lift Equipment GTJZ06
6m Platform Small Scissor Lift , Lightweight Scissor Lift Equipment GTJZ06
6m Platform Small Scissor Lift , Lightweight Scissor Lift Equipment GTJZ06
6m Platform Small Scissor Lift , Lightweight Scissor Lift Equipment GTJZ06
6m Platform Small Scissor Lift , Lightweight Scissor Lift Equipment GTJZ06
6m Platform Small Scissor Lift , Lightweight Scissor Lift Equipment GTJZ06
6m Platform Small Scissor Lift , Lightweight Scissor Lift Equipment GTJZ06
Specifications
Place of Origin :
Henan, China (Mainland)
Brand Name :
JIANGHE
Certification :
CE ISO9001 SGS
Supply Ability :
300 Unit/Units per Month
Packaging Details :
standard export package/container or as required
MOQ :
1 Unit/Units
Price :
Negotiable
Lift Mechanism :
Scissor Lift
Power :
3kw
Rated Loading Capacity :
230kg
Lift Drive / Actuation :
Hydraulic
Table Size :
1670mm*740mm
Min. Lifting Height :
2.19m
Max. Lifting Height :
6m
Overall Dimensions :
1860mm*760mm*2190mm
Weight :
1260kg
Color :
Blue&Grey
Voltage :
6v*4/224Ah/120-360V
Application :
Widely
Description
JHC Hot High Quality 6m scissor lift for sale GTJZ06

Product Application

6m-14M self propelled scissor lift is widely used in places and applications such as factory plants, railway stations, highways, airports, petroleum companys, power grids, halls, hotels, overhauling, chemical engineering, medicines, army troops, nuclear power industry, fire fighting, stadiums, community property management and etc.

Main Features

1) Self-propelled hydraulic powered.
2) Solid non-marking tires to suit tough outdoor working conditions.
3) Manual platform lowering valve in case of machine breaking down.
4) On-board Diagnostic system to save time and manpower maintenance.
5) Pothole guards and tilt level sensor to guarantee operator's safety.
6) Emergency stop to avoid potensial denger.
7) Flexible operation, low noise, zero emission.

Scissor Lifts Specifications
ModelGTJZ06GTJZ08GTJZ10GTJZ12GTJZ14
Capacity230KG230KG320KG320KG200KG
Platform Height7.8M10.1M12M13.8M15.7M
Length5.8M8.1M10M11.8M13.7M
Width0.76M0.83M1.17M1.17M1.27M
Height2.19M2.37M2.49M2.62M2.62M
Weight1260KG2100KG2480KG3100KG3180KG

Aerial work platform in accordance with the arm exhibition forms can be divided into ZhiBeiShi and crank arm type two kinds, crank arm type aerial work platform using multilevel folding arm combination design, flexible, convenient and can span the barrier, in a lift for more work.Better security, mobile convenience, but cost is tall.Crank arm overhead working flat wagon is widely suitable for use in urban management, power, street lamp, advertising, communications, framing, gardens, transportation, port, airport, port, large industrial and mining companies in sectors such as installation and maintenance and high homework.

Standard:
1) Proportional control
2) Platform gate with automatic lock
3) Platform extension deck
4) Full stroke travel
5) Solid stroke travelt
6) 4*2 drive
7) Automatic brake system
8) Emergency lowering system
9) Emergency stop button
10) Oil pipe explosion proof system
11) Fault diagnosis system

6m Platform Small Scissor Lift , Lightweight Scissor Lift Equipment GTJZ06
6m Platform Small Scissor Lift , Lightweight Scissor Lift Equipment GTJZ06


Company Information
Established in 1992 and with its corporate headquarter located in the City of ZhengZhou, China, Henan Jianghe Crane Co., Ltd. is a leading manufacturer specialized in producing Lifting Equipment, such as gantry crane, overhead crane, portal crane, aerial work platform, etc., Steel-plate Bending Equipment, and Flatbed Transporter. Our products are widely used in shipbuilding industry, aircraft manufacturing and maintenance facilities, high speed rail construction projects, nuclear power plants, automotive factories, oil and gas sector, etc.
Henan Jianghe Crane Co., Ltd. is an ISO9001 registered company. All products are in full compliance and meeting the standards and certification issued by China Quality Certification Center. We offer our customers the best in quality, design, reliability and durability. Our main focus is customer service and to exceed our customers’ expectations.
