Specifications
Place of Origin :
Henan, China (Mainland)
Brand Name :
JIANGHE
Model Number :
GTJZ10
Certification :
CE ISO9001 SGS
Supply Ability :
300 Unit/Units per Month
Packaging Details :
standard export package/container
MOQ :
1 Unit/Units
Price :
Negotiable
Lift Mechanism :
Scissor Lift
Lift Drive / Actuation :
Hydraulic
Power :
3kw
Rated Loading Capacity :
320kg
Min. Lifting Height :
2.48m
Max. Lifting Height :
10m
Table Size :
2270mm*1170mm*1370mm
Overall Dimensions :
2420mm*1170mm*2480mm,
Weight :
2440kg
Color :
Blue&Grey
Voltage :
6v*4/224Ah/120-360V
Application :
Widely
Feature :
Easy Operation Safety Convenience
Type :
Solid Tyre
Use :
Hydraulic Maintenance Platform
battery :
trojan
community :
IPAF
After-sales Service Provided :
Overseas third-party support available
Warranty :
2 Years
Port :
TIANJIN/QINGDAO/SHANGHAI
Description
Quality awp indoor out door hydraulic scissor lift for sale
Product Description

JIANGHE GTJZ series electrical and hydraulic Scissor working platform provide you incomparable reliability and versatility - enhance efficiency . As the ideal model for flexible operation in crowded space , it is suitable for both flat and rugged ground indoor and outdoor construction, repairing and installation . JIANGHE GTJZ series have the features of low noise , higher loading capacity and larger work platform .

Excellent mobility, Compact body can easily pass through single and double channel doorway , using non-marking solid tire.

3 Special Locations , Feature of low noise is perfectly suitable for the noise-sensitive environment , such as office buildings , shopping malls , hotels . schools etc .

what is the details of our battery power scissor lifts ?

1. self-propelled hydraulic powered.

2. solid non-marking tires to suit tough outdoor working conditions.

3. manual platform lowering valve in case of machine breaking down.

4. on-board diagnostic system to save time and manpower maintenance.

5. pothole guards and tilt level sensor to guarantee operators' safety.

6. emergency stop to avoid potential danger.

7. compact body and excellent mobility.

8. flexible operation and low noise, zero emission.

What is the specifications of our battery power scissor lifts?

Models GTJZ10
Dimensions
Plalfbrm Height Max 32.8ft (10m)
Working Height Max 39.4(1 (12m)
Platlorm Extended 2.95ft (0.9m)
Length-slowed 7.9ft (2.42m)
Width-stowed 3.8ft (1.17m)
Height-stowed 8. Ill (2.48m)
Wheelbase 6.2ft (1.88m)
Ground Clearance 0.33ft (0.1m)
Platform Sizc(L*W*H) 7.7*3.8*3.6ft 2.3*1.17*1.Im
Productivity
Max Platform Occupancy 2
Lili Capacity 7O5lbs (320kg)
Lin Capacity-extension deck 249lbs(ll3kg)
Drive Speed-stowed 0-2.2mph (0-3.5km/h)
Drive Speed-raised 0-0.5mph (0-0.8km/h)
Gradcabilily 25%
Turning Radius-Inside Oft (Om)
Turning Radius-Outside 7fl(2.14m)
Raisc/Lowcr Speed 45s/35s
Controls Proportional
Drives Dual front wheel
Brakes Dual rear wheel
Tire Sizc(Solid non-marking) l3.3*4.1ft(406*l25mm)
Power
Power Source 24V(4*6V225Ah Batteries)
Hydraulic System Capacity 4.2gal(16L)
Weight
indoor 48721bs (2210kg)
Standards Compliance CE/ISO/1PAF

Packaging details:

The whole machine is packaged in polythene woven cloth and plywood case or according to clients’ requirement.

Delivery details:

1. Payment: T/T, Western Union, MoneyGram,PayPal; 30% deposits; 70% balance before delivery.

2. MOQ: 1pcs

3. Warranty : 2 years

4. Delivery Time: 15-30 days for batch goods.

5. Customers specifying freight forwarders or negotiable shipping methods.

Why choose us?

1.We are Alibaba Assessed 2 years Gold Supplier.

2.We are a factory manufacturing scissor lifts,articulating boom lifts and telescopic boom lifts,best production capability ,best quality control, Best Service .

3. 100% QC inspection Before Shippment.

4. CE/IPAF/ISO listed,competitve price.

Company Information

Established in 1992 and with its corporate headquarter located in the City of ZhengZhou, China, Henan Jianghe Crane Co., Ltd. is a leading manufacturer specialized in producing Lifting Equipment, such as gantry crane, overhead crane, portal crane, aerial work platform, etc., Steel-plate Bending Equipment, and Flatbed Transporter. Our products are widely used in shipbuilding industry, aircraft manufacturing and maintenance facilities, high speed rail construction projects, nuclear power plants, automotive factories, oil and gas sector, etc.

Henan Jianghe Crane Co., Ltd. is an ISO9001 registered company. All products are in full compliance and meeting the standards and certification issued by China Quality Certification Center. We offer our customers the best in quality, design, reliability and durability. Our main focus is customer service and to exceed our customers’ expectations.

Power Pneumatic Upright Scissor Lift , Portable Scissor Lift Trojan Battery Incomparable Reliability

Q1: What is the warranty for the aerial work platforms?

A1: For the products,we have 2 years warranty.If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.

Q2: How to Guarantee the qualities?

A2: most of our main components are imported from USA,Itay and etc, such as perkins and cummins engine.all the export products are carefully examined for 3 times before shipping.

Q3: If qualities problems happen, what should you do?

A3: we have established a muture after-sales network, professional hydraulic engineers and electrical engineers will offer help 24 hours online.

Q4: Will you offer operation and maintenance traninging?

A4: Yes, for all our customers, we have prepared full operation and maintenance courses to help you operate the machine.

Q5: If I buy in large quantities, do you have any preferential policy?

A5: Yes, if buying in large quantities, we will offer finance installment service and old-for-new ones service.

Q6: Can we get support if we have our own market position?

A6: Yes, now we are promoting overseas dealer policy, for dealers purchasing and selling our products in your country, we will offer a series of preferential policies such as competitive prices, preferential order manufacturing, face-to-face training and longer warranty and etc.
