Specifications
Brand Name :
JIANGHE
Model Number :
16
Certification :
CE ISO9001 SGS
Place of Origin :
Henan
MOQ :
1unit
Price :
Negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
300 units/month
Delivery Time :
15-30 days
Packaging Details :
The whole machine is packaged in polythene woven cloth and plywood case or according to client's requirement
Color :
yellow
Transmission type :
Manual
Emission standard :
Euro 3
Description :
Vehicle Platform Truck
Description

Main features

Compact structure,wide working radius

Famous brand chassis truck

Electric and hydraulic proportional control,run stable, stepless speed regulation

The upper and lower structure automatically interlock,safe and reliable operation

Product application

16m Truck-mounted aerial work platforms(AWPs)

Performance

Classifications Item Unit Parameter
Dimension Overall Length L mm 5910
Overall Width W mm 2000
Overall Height H mm 2900
Weight Cabin people 2
Total weight kg 4490
Driving Max drive speed Km/h 100
Min ground clearance mm 195
approach angle α . 24
departure angle β . 10
Main performance Rated lift Capacity Kg 200
Max working height m 16.1
max working height working radius m 1.45
max working radius m 10.6
max working radius working height m 4.76
Outrigger span longitudinal mm 3280
transverse mm 2800
