Specifications
Brand Name :
Mercury
Model Number :
CCDD-60L CCDD-30L CCDD-150L
Place of Origin :
China Zhengzhou
MOQ :
1 PCS
Price :
USD 850 - 980 PCS
Payment Terms :
T/T, Paypal
Supply Ability :
2000 PCS per month
Delivery Time :
Within 2 days
Packaging Details :
Carton 63cm*33cm*33cm
Color :
Black
Description
Wire,Cable Length Measuring Machine, Length measurement, Wire, Cable meter counter gauge.
CCDD series belt type counter will provide you with the industry's most accurate measurement. reduce your production costs. Electronic controller unit can do preset in length, alarm time, and a variety of customized signal output.
Wire Cable Length Measuring Machine. Lenth meter counter. Length measurement Model CCDD-60L CCDD-30L
Wire Cable Length Measuring Machine. Lenth meter counter. Length measurement Model CCDD-60L CCDD-30L

Features
1. Designed for wire and cable pipe meter and design process, high precision.
2. LED display is clear and easy reading.
3. Electronic controller unit provides multiple sets of relay output, easy to manage the production automatically .
4. High accuracy,up to +/- 0.1%
5. Positive or reverse two-way adjustable counting
6. Emergency power down data protection
7. CCDD-150L is specially designed with air cylinder unit.
8. Counter support height can be adjusted to adapt to different heights of the production line.
9. The position of decimal point on display is adjustable..
10.Standard Belt,easy to find replacement belt in market.
Wire Cable Length Measuring Machine. Lenth meter counter. Length measurement Model CCDD-60L CCDD-30L
Wire Cable Length Measuring Machine. Lenth meter counter. Length measurement Model CCDD-60L CCDD-30L

Technical parameters:
The model CCDD-30L is used for measuring the length of cable ( external diameter between 1mm - 30mm ).
The model CCDD-60L is used for measuring the length of cable ( external diameter between 1mm - 50mm ).
The model CCDD-150L is used for measuring the length of cable ( external diameter between 3mm - 150mm ).

Specifications

Model CCDD-30L CCDD-60L CCDD-150L
Measuring Range 3-30mm 3-50mm 3-150mm
Max Counting Length 9999999 999999 999999
Max Total Length 99999.99 99999.99 99999.99
Accuracy +/- 0.1% +/- 0.1% +/- 0.1%
Dimension 410x180x1200mm 430x225x1200mm 490x370x590mm
Total Net Weight 17KG 22KG 55KG
Max Measuring Speed 400 m/min 400 m/min 400 m/min
Relay Output 2 2 2
Alarm Output Yes Yes Yes
Display digits 7 digit 7 digit 7 digit
Length Measuring Unit Meter Meter Meter
Calibration Yes Yes Yes
Decimal Point Shift Yes Yes Yes
Length Preset Yes Yes Yes
Ahead of Preset Output Yes Yes Yes
Control Preset Yes Yes Yes
Emergent Data Protection Yes Yes Yes
Two-Direction Counting Yes Yes Yes
Ft Measuring Unit Option Option Option
RS485 Option Option Option
Power Consumption <10W <10W <10W
Voltage

220V

50/60HZ

220V

50/60HZ

220V

50/60HZ

Wire Cable Length Measuring Machine. Lenth meter counter. Length measurement Model CCDD-60L CCDD-30L

Wire Cable Length Measuring Machine. Lenth meter counter. Length measurement Model CCDD-60L CCDD-30L

If you have any questions, please connect to us:
E-mail: shuhong@cnmeasure.com
Website: www.cnmeasure.com
TEL: +86-135 9803 3248
Skype number: cnmeasure
Address: NO.36 Hongsong Road, High-tech Zone, Zhengzhou, CHINA,
Manufacturer: Zhengzhou Mercury-tech Co.,Ltd.
