Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603
Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603
Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603
Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603
Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603
Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603
Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603
Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603
Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603
Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603
Specifications
Brand Name :
CNOEC, OPTO-EDU
Model Number :
A14.2603
Certification :
CE, Rohs
Place of Origin :
China
MOQ :
1 pc
Price :
FOB $1~1000, Depend on Order Quantity
Payment Terms :
T/T, West Union, Paypal
Supply Ability :
5000 pcs/ Month
Delivery Time :
5~20 Days
Packaging Details :
Carton Packing, For Export Transportation
Eyepiece :
WF10x/22
Nosepiece :
4 Holes
Objectives :
Achromatic 10x20x40x, Phase Contrast 20x
Working Stage :
Attached mechanical stage
Condenser :
Abbe N.A.0.3
Focusing :
Coaxial Coarse & Fine
Light Source :
Halogen 6V30W
Power Supply :
100~240V
Size :
L40*W20*H54CM
Weight :
13.6KG
Description

OPTO-EDU A14.2603 Trinocular Phase Contrast Inverted Biological Microscope

A14.2603 Inverted Biological Microscope is a kind of microscope whose objective is under the stage. The special design is for observing and operating specimen more convenient, especially for specimen of height. It’s stage is mechanical stage, size 210x241mm, the round slide size is dia.118mm, with attachable mechanical stage for 96 holes plate, moving range 128x80mm. The illumination is transmit light, Koehler illumination halogen 6V30W.

Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603

Parameter

A14.2603 Inverted Microscope Specification
Head Seidentopf Trinocular Head, Inclined 45°, Interpupillary Distance 48~76mm
Light Split (Both) 100:0 and 80:20
Eyepiece WF10x/22mm, Diopter Adjustable
Nosepiece Large Diameter Quintuple
Objective LWD Infinity Plan Objective
LPL10x/0.25 WD=8.3mm
LPL20x/0.40 WD=7.2mm
LPL40x/0.60 WD=3.4mm
LWD Infinity Plan Phase Contrast Objective
20x/0.40 WD=7.2mm
Focus System Low Position, Coaxial Coarse & Fine Focusing System, Coarse Stroke 42mm /Rotation, Fine Stroke 0.2mm /Rotation, Minimum Reading 2μm
Stage Mechanical Stage Size 210x241mm, Round Slide Size Dia.118mm, With Attachable Mechanical Stage For 96 Holes Plate, Moving Range 128x80mm, With Culture Dish Holder 54mm, Knob Can Be Changed By Left Or Right
Condenser Long Working Distance, N.A.0.3, Working Distance 72mm (With Condenser), 195mm (Without Condenser For Extra High Culture Dish), Quickly Detachable
Phase Contrast Phase Contrast Annular Plate For 20x/40x
Filter Blue, Green
Light Source Transmit Light, Halogen 6V30W, Koehler Illumination
Power Supply Wide Range Voltage 110~240V

Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603

Product Display

Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603

Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603

Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603

Product Details

Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603

Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603

Related Products

Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603

Product Application

Inverted microscope is particularly suitable for living cells and tissues, fluids, sediments and other microscopic research. It is the ideal instrument for biology, cytology, oncology, genetics, immunology and other research work. Inverted microscope is widely used in scientific research, universities, medical, epidemic prevention and agriculture and animal husbandry and other departments.

Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603

Packaging & Shipping

Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603

Company Information

Trinocular Phase Contrast Inverted Optical Microscope OPTO-EDU A14.2603

OPTO-EDU, as one of the most professional manufacturer and supplier of microscope in China, our sub-brand CNOPTEC series high end biological, laboratory, polarizing, metallurgical, fluorescene microscopes, CNCOMPARISON series forensic microscope, A63 series SEM microscope, and .49 series digital camera, LCD camera are very popular in the world market.
