Inverted Biological Microscope, BF+PH, ECO

• Infinity Color Corrected Optical System + Positive Phase Contrast
• Plan WF10x/22mm, Diopter Adjustable, High Eye-point
• Infinity LWD Plan Achromatic Objective 4x/10x/40x & Phase Contrast 20x
• Phase Contrast Filter & Centering Telescope
• 5W LED With Light Indicator, With ECO Auto On/Off Function

•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

• A14.0912 Biological, A16.0912-L Fluorescent, A13.0912 Metallurgical Series Inverted Microscope		A14.0912 Biological	A16.0912-L Fluorescent	A13.0912 Metallurgical	Cata. No.
  Observation Method	Bright Field	●	●	●
  	Phase Contrast	●	●	-
  	Fluorescent	-	●	-
  	Dark Field ( With BF/DF Shifter)	-	-	●
  	Polarizing	-	-	●
  	DIC	-	-	●
  Head	Trinocular Head, 45° Inclined, 360° Rotatable, IPD 50-75mm, Light Split Ratio 50:50	●	-	-
  	Trinocular Head, 45° Inclined, 360° Rotatable, IPD 50-75mm, Light Split Ratio 100:0/0:100 Switchable	-	●	●
  Eyepiece	Wide Field Plan PL10x/22mm, High Point, Diopter Adjustable	●	●	●	A51.0904-1022T
  	Wide Field Plan PL10x/22mm, High Point, Diopter Adjustable With Reticle	○	○	○	A51.0904-1022R
  	Wide Field Plan PL15x/16mm, High Point, Diopter Adjustable	○	○	○	A51.0904-1516T
  Nosepiece	Quintuple	●	●
  	Coded BD Quintuple With DIC Slot, Show Objective On Front Panel	-	-	●
  Objective	Infinity LWD Plan Achromatic 4x/0.10, W.D.22mm, Cover Glass 1.2mm	●	○	-	A5M.0935-4
  	Infinity LWD Plan Achromatic 10x/0.25, W.D.7.94mm, Cover Glass 1.2mm	●	○	-	A5M.0935-10
  	Infinity LWD Plan Achromatic 20x/0.50, W.D.7.66mm, Cover Glass 1.2mm	○	○	-	A5M.0935-20
  	Infinity LWD Plan Achromatic 40x/0.60, W.D.3.71mm, Cover Glass 1.2mm	●	○	-	A5M.0935-40
  	Infinity LWD Plan Achromatic 60x/0.70, W.D.2.50mm, Cover Glass 1.2mm	○	○	-	A5M.0935-60
  	Infinity LWD Positive Phase Contrast 4x/0.13 WD=10.75mm	○	○	-	A5C.0938-4
  	Infinity LWD Positive Phase Contrast 10x/0.25 WD=7.45mm	○	○	-	A5C.0938-10
  	Infinity LWD Positive Phase Contrast 20x/0.40 WD=6.92mm	●	○	-	A5C.0938-20
  	Infinity LWD Positive Phase Contrast 40x/0.65 WD=2.74mm	○	○	-	A5C.0938-40
  	Infinity LWD Plan Fluorescent LWDPL4x/0.13, W.D.18.52mm	-	●	-	A5F.0932-4
  	Infinity LWD Plan Fluorescent LWDPL10x/0.3, W.D.7.11mm	-	●	-	A5F.0932-10
  	Infinity LWD Plan Fluorescent LWDPL20x/0.45, W.D.5.91mm	-	○	-	A5F.0932-20
  	Infinity LWD Plan Fluorescent LWDPL40x/0.65, W.D.1.61mm	-	○	-	A5F.0932-40
  	Infinity LWD Plan Fluorescent LWDPL60X/0.75, W.D.1.04mm	-	○	-	A5F.0932-60
  	Infinity LWD Plan Semi-APO Phase Contrast & Fluorescent LWDPL20x/0.45 W.D.5.91mm	-	●	-	A5F.0933-20
  	Infinity LWD Plan Semi-APO Phase Contrast & Fluorescent LWDPL40x/0.65 W.D.1.61mm	-	●	-	A5F.0933-40
  	Infinity LWD BD DIC Plan Metallurgical DIC-5x/0.15 W.D.11mm	-	-	●	A5M.0939-5
  	Infinity LWD BD DIC Plan Metallurgical DIC-10x/0.3 W.D.9.5mm	-	-	●	A5M.0939-10
  	Infinity LWD BD DIC Plan Metallurgical DIC-20x/0.45 W.D.3.4mm	-	-	●	A5M.0939-20
  	Infinity LWD BD Semi-APO Plan Metallurgical FL50x/0.55 W.D.7.5mm	-	-	●	A5M.0940-50
  	Infinity LWD BD Semi-APO Plan Metallurgical FL100x/0.8 W.D.2.1mm	-	-	○	A5M.0940-100
  Focusing	Coaxial Coarse & Fine Focusing, With Tension Adjustment Ring, Coarse Focusing Range 9mm, Up 6.5mm + Down 2.5mm, Fine Focusing Precision 0.002mm	●	●	●
  Working Stage	Three-Layer Mechanical Stage, Size 240x250mm, Moving Range 50x50mm, Bothway Linear Guide Rail, Right Hand Controls, Low Position	-	-	●
  	Fixed Working Stage, Size 215x250mm	●	●	-
  	Attachable Mechanical Stage, Moving Range 120(X)x78(Y)mm	○	●	-	A54.0945-02
  	Stage Extension Plate	○	●	-	A54.0945-E1
  	Glass Plate With Round Hole	●	●	-	A54.0945-GP
  	Metal Round Plate, Hole Dia.25mm	-	-	●	A54.0945-M1
  	Metal Round Plate, Hole Dia.12mm	-	-	○	A54.0945-M2
  	Metal Plate With Kidney Hole	●	●	-	A54.0945-M3
  	Petri Dish Holder, Hole Dia.35mm	●	●	-	A54.0945-H1
  	Slides Holder, Hole Dia.54mm + 26.5x76.5mm	○	●	-	A54.0945-H2
  	Teraseki Holder, Hole Dia.65mm + 56x81.5mm	○	●	-	A54.0945-H3
  Condenser	LWD Condenser N.A. 0.30, W.D. 72mm, Dismountable, With Phase Contrast Slot	●	●	-
  Phase Contrast	Centre-Adjustable Phase Contrast Slide Plate, For 4x10+20x40x Objectives	●	●	-
  	Centering Telescop Dia.30mm	●	●	-
  Polarzing	Polarizer & 360° Analyzer	-	-	●
  DIC	DIC Slider	-	-	○	A5M.0955
  Transmit Light Source	5W LED Illumination, Intensity Adjustable	●	●	-
  	LBD Color Temperature Change Filter Dia.45mm	●	●	-
  	IF550 Green Interference Filter Dia.45mm	●	●	-
  Reflect Light	12V100W Halogen Light Source, Brightness Adjustable	-	-	●
  Reflect Fluorescent Light Source	LED Fluorescent Lamp House, 4 Bands LED Switching By Servo Motor, Built-in LEDs For Fluorescent Filter 385nm, 470nm, 560nm.	-	●	-
  	3 Bands Fluorescent Filter Switching Mechanism, Automatically Switch Filters & LED Light Together And Show Fluorescent Filter On Front Panel	-	●	-
  	Fluorescent Filter B1 470nm	-	●	-	A5F.0924-B1
  	Fluorescent Filter G1 560nm	-	●	-	A5F.0924-G1
  	Fluorescent Filter V1 410nm	-	○	-	A5F.0924-V1
  	Fluorescent Filter UV1 385nm	-	○	-	A5F.0924-UV1
  Main Body	Reflect and Transmit Frame Body	●	●	-
  	Reflect Frame Body	-	-	●
  Front Panel	ECO Auto On/Off Function Switch	●	●	●
  	Light Indicator	●	●	●
  	Fluorescent Band Indicator	-	●	-
  	Objective Indicator, Work With Coded Nosepiece	-	-	●
  Power Supply	External Wide Voltage Transformer, Input 100-240V	●	●	●
  Camera Adapter	C-Mount 0.35x	○	○	○	A55.0934-35
  	C-Mount 0.65x	○	○	○	A55.0934-65
  	C-Mount 0.5x	○	○	○	A55.0934-05
  	C-Mount 1.0x	○	○	○	A55.0934-10
  Packing	Foam+Carton, 1pc/Carton, 68*67*47cm, G.W.21Kgs	●	-	-
  	Foam+Carton, 1pc/Carton, 74*67*57cm, G.W.24Kgs	-	●	-
  	Foam+Carton, 1pc/Carton, 49*51*73cm, G.W.22Kgs	-	-	●
  Note:"●"In Table Is Standard Outfits,"○" Is Optional Accessories "-" Is Unavailable

•
•
•
•
•
•
