150V 5A 2.5mm Pitch SMD Phoenix Screw Terminal spring type terminal block
150V 5A 2.5mm Pitch SMD Phoenix Screw Terminal spring type terminal block
Specifications
Model :
2025BV-2.5
Brand :
SHAN YE
Conductor Size :
0.2-6.0
Type :
spring type terminal block
Material :
PA66plastic,UL94V-0 ,Copper alloy
Color :
Green,Black,other color can custom
Place of Origin :
China
Brand Name :
Shanye
Price :
negotiable
Packaging Details :
carton box
Payment Terms :
Western Union, MoneyGram, T/T
Description

SHANYE BRAND 2025BV-2.5 150V 5A 2.5mm pitch Newest model phoenix smd screw terminal with high quality

Product Specifications

Pitch 2.24mm
Poles 2P-24P
Number of Contacts 2-24
Rated voltage 150V
Reated current 5A
Pin Dimensions) [mm 3.7
Temperature range -40°C~+105°C
(Impulse wiithstand voltagea) [KV]

2.5
Supply Ability 100000 Piece/ per Week
Stripping Length) [mm] 15-16
Contactive Coating Tin Plated
Withstanding VoltagWithstanding Voltag 2200V/1Min
PCB Hole Diameter) [mm] 1.4

Product Application

  • industrial controls

  • lamp lighting

  • instrumentation

  • consumer electronics telecom equipment

  • transportation

Drawing

150V 5A 2.5mm Pitch SMD Phoenix Screw Terminal spring type terminal block2025BV-2.5.pdf

Package Details

  • Pluggable Terminal Blocks: Inner Box first , then Inner Carton, The last, Export Carton.

Take strong bags/boxes/cartons for the package, in order to reduce the damage during the shipments. Tape and reel packing, Clamshell packing, Pallet packing, etc are available.

  • Export Carton size:43*27*27/36CM

  • Port: NINGBO/SHANGHAI

FAQ

Q: The nature of the company (factory/trading)?

A: Integrated industry and trade.

Q: Packing details of the product?

A: Use a special export carton, which is stronger, and the weight of a single piece does not exceed 25KG (by air).

Q: The customs code of the product?

A: 8536901900.

Q: The mass production time of the product?

A: Usually 2 weeks - 4 weeks.

Q: Is the sample provided for free, and the sample delivery date?

A: Small amount samples can be given away for free, and samples can be delivered within 3-5 days.

Q: Does the product support OEM customization?

A: YES.

Q: Do you support MOQ?

A: YES.

Q: Is there a product quotation or electronic sample catalog?

A: Customers need it at any time and can provide it at any time.

Q: Does the company have quality control standards and corresponding management systems?

A: Of course.

SHIPMENTS

150V 5A 2.5mm Pitch SMD Phoenix Screw Terminal spring type terminal block
