ZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal
ZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal
Specifications
Place of Origin :
China
Brand Name :
CCRB
Certification :
ISO9001:2008, SGS
Model Number :
ZYQS
MOQ :
1 Set
Price :
Negotiated
Packaging Details :
Standard export package
Delivery Time :
Within 40 days
Payment Terms :
L/C, T/T
Supply Ability :
600 sets per year
Description

ZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal

ZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal

Introduction:

ZYQS Series High Amplitude Vibrating Screen is a new kind of screening equipment to solve the deep screening problem of wet sticky material. It has perfectly solved the problem that the wet sticky raw coal less than 10mm plugged the screen mesh. The high amplitude screen is mainly used in the stock yard of metallurgical industry, handling system of coal industry, desulfurization of power plant (CFB).

ZYQS Series High Amplitude Vibrating Screen for Wet Sticky CoalZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal

High Amplitude Screen Excellent Features:

  • With large amplitude and high vibration strength, but with low vibration frequency.
  • The screen surface with multi-section type, the screen box doesn’t participate in vibration, only screen mesh vibrating.
  • The high amplitude screen adopts a full enclosure design to ensure a clean working environment.
  • It is connected by flexible joints and controlled by PLC system.
  • The screen is specially designed for handling wet feedstock.
  • With a low dynamic load and screen surface self-cleaning function, easy to maintain.
High Amplitude Screen Technical Parameters
No. Model Screen Surface

Feeding Size

(mm)

 Capacity (m³/h) Motor
Deck Area (m²)

Angle

(°)

Screen Mesh

(mm)

 Power (KW) Qty
1 ZYQS-1520 1 3.0 20 5~80 <300 50-250 7.5 1
2 ZYQS-1536 1 5.4 20 5~80 <300 100-400 7.5 2
3 ZYQS-1850 1 9.0 20 5~80 <300 180-650 7.5 3
4 ZYQS-2050 1 10.0 20 5~80 <300 250-800 7.5 3
5 ZYQS-2560 1 15.0 20 5~80 <300 320-1200 11 3
6 ZYQS-2876 1 21.28 22 5~80 <300 380-1500 11 4
7 ZYQS-3085 1 25.5 22 5~80 <300 420-2000 11 5
8 ZYQS-30100 1 30.0 22 5~80 <300 450-2200 11 6
9 ZYQS-3685 1 30.6 22 5~80 <300 480-2500 11 6
10 ZYQS-36100 1 36.0 22 5~80 <300 500-2800 11 7
11 ZYQS-4085 1 34.0 22 5~80 <300 550-3000 11 6
12 ZYQS-40120 1 48.0 22 5~80 <300 650-3800 11 8

ZYQS Series High Amplitude Vibrating Screen for Wet Sticky CoalZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal

Related Products:

Circular Vibrating Screen&Coal Sizer

ZYQS Series High Amplitude Vibrating Screen for Wet Sticky CoalZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal

Coal Crushing Plant&Banana Screen

ZYQS Series High Amplitude Vibrating Screen for Wet Sticky CoalZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal

Apron Feeder Breaker&Scraper Feeder Breaker

ZYQS Series High Amplitude Vibrating Screen for Wet Sticky CoalZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal

Crawler Type Mobile Crushing Plant&Trailer Type Mobile Crushing Plant

ZYQS Series High Amplitude Vibrating Screen for Wet Sticky CoalZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal

Vibrating Feeder&Belt Feeder

ZYQS Series High Amplitude Vibrating Screen for Wet Sticky CoalZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal

Portable Jaw Crusher&Impact Crusher

ZYQS Series High Amplitude Vibrating Screen for Wet Sticky CoalZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal

Cone Crusher&Sand Making Machine

ZYQS Series High Amplitude Vibrating Screen for Wet Sticky CoalZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal

Impeller Sand Washer&Spiral Sand Washer

ZYQS Series High Amplitude Vibrating Screen for Wet Sticky CoalZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal

After-sales Service:

Provide professional staff training for customers

1. Service engineer offers spot training and equipment operation manual.

2. After-sales personnel visit customers on a regular basis.

3. Design engineer provides professional service for customers for free.

Company Information:

ZYQS Series High Amplitude Vibrating Screen for Wet Sticky CoalZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal

ZYQS Series High Amplitude Vibrating Screen for Wet Sticky Coal
