G Type Public Transport Bus 12-27 Seats , Tourism CNG Powered Bus 7.7 Meter Length
G Type Public Transport Bus 12-27 Seats , Tourism CNG Powered Bus 7.7 Meter Length
G Type Public Transport Bus 12-27 Seats , Tourism CNG Powered Bus 7.7 Meter Length
G Type Public Transport Bus 12-27 Seats , Tourism CNG Powered Bus 7.7 Meter Length
G Type Public Transport Bus 12-27 Seats , Tourism CNG Powered Bus 7.7 Meter Length
G Type Public Transport Bus 12-27 Seats , Tourism CNG Powered Bus 7.7 Meter Length
G Type Public Transport Bus 12-27 Seats , Tourism CNG Powered Bus 7.7 Meter Length
G Type Public Transport Bus 12-27 Seats , Tourism CNG Powered Bus 7.7 Meter Length
G Type Public Transport Bus 12-27 Seats , Tourism CNG Powered Bus 7.7 Meter Length
G Type Public Transport Bus 12-27 Seats , Tourism CNG Powered Bus 7.7 Meter Length
G Type Public Transport Bus 12-27 Seats , Tourism CNG Powered Bus 7.7 Meter Length
G Type Public Transport Bus 12-27 Seats , Tourism CNG Powered Bus 7.7 Meter Length
Specifications
Brand Name :
MUDAN
Model Number :
G8 (MD6771N)
Certification :
ISO9001,CCC
Place of Origin :
ZHANGJIAGANG,CHINA
MOQ :
I UNIT
Price :
negotiation
Payment Terms :
T/T
Supply Ability :
10000 UNITS PER YEAR
Delivery Time :
35 WORKING DAYS
Packaging Details :
BULK OR CONTAINER
Product Name :
city bus
Model/ Type :
G type
Length :
7.7 Meter
Engine type :
CNG
Seats capacity :
49~58/12~27
Gearbox :
Manual
Description

G Type Public Transport Bus 12-27 Seats , Tourism CNG Powered Bus 7.7 Meter Length

Quick details:

A: City bus

B: 4214cc CNG engine

C: 7.7 meter G type

Description:

Our G series are developed by mudan company according to local market demand .No matter big cities or small cities,even under narrow road at moutainous countryside. Our city bus can work quite well.

With advanced design concepts, it can carry maximum 58 passenger at one time, which includes 12~27 pcs seat capacities.

12-27 Seats CNG Tourism Bus


Model year :2016


Delivery lead time: within 35 working days after the payment is confirmed.

Specification:

Model

MD6771N

Overall Dimension

Length (mm)

7,700

Width (mm)

2,400

Height (mm)

3,100

Wheel base (mm)

3,500

Vehicle Weight

Curb (kg)

3,850

Gross (kg)

7,500

Seating capacity

Pcs

12~27

Fuel tank (L)

70

Tires

Quantity

6+1

Size

8.25-16

Engine

Model

YC4D140N-50

Emission Level

Euro 5

Manufacturer

YUCHAI

Displacement (cc)

4214

Max. power (Hp/rpm)

140/2,800 (103kw/2,800rpm)

Max. torque (Nm/rpm)

420/1,400~1,800

Gear Box

5 speed mannual transmission

Seats type

PVC rubber seat

Body Structure

All metal type, semi-integral body

Standard Configuration:

1. Front laminated glass, rear tempered glass

3. Sunroof

4. Normal interior

5. MP3 player & 4 speaker

6. PVC floor

7.Stainless wheel cover

8. Front Defrosting system

9. One driver door, Pneumatic folding front & middle passenger door

G Type Public Transport Bus 12-27 Seats , Tourism CNG Powered Bus 7.7 Meter Length
