Specifications
Brand Name :
DBM
Model Number :
009
Place of Origin :
China
Certification :
ISO, SGS, BV
MOQ :
25 tons
Price :
700~850usd/ton
Packaging Details :
Standard Export package with wooden pallet
Delivery Time :
30 days
Payment Terms :
TT, LC, DP, DA
Supply Ability :
800 tons/day
Organic Coating Thickness :
20μm~45μm
Baseplate :
Galvanized Or Galvalumed
Back Coating :
5-7micron
Tensile Strength :
G300-G550
Length :
1000m, 1100m
Metal :
Hot Dipped Galvanized Steel
Coil Id :
508mm And 610mm
Coating Material :
Color
Special Use :
Weather Resistant Steel Plate
Coil Weight :
3-8 tons
Processing Service :
Cutting, Decoiling
Tolerance :
±1%
Type :
Steel Plate, Galvalume Steel Sheet
Surface State :
Bright And Smooth
Paint Thickness :
min:15um;max:25um
Coated Layer :
2/2 or 2/1
Paint Type :
PE/SMP/HDP/PVDF
Coating Thickness :
0.2-1.2mm
Back Side :
5-8μm
Yield Strength :
195-420MPA
Surface Hardness :
≥2H
Impact Resistance :
≥9J
Description

0.50*1250 European Market Painted Steel Coils PE paint 10 Years Warranty Z100 Galvanized Color Coated Coil

Product Description:

Introduction

Colour coated coil is a highly versatile product that is made by using substrates such as hot-dip galvanized sheet, hot-dip aluminium zinc plated sheet, and electro-galvanized sheet. The manufacturing process involves a pre-treatment procedure which includes chemical degreasing and chemical conversion treatment, followed by coating one or several layers of organic paint. The painted sheet is then baked and cured to achieve a durable and aesthetically pleasing finish. These coils are referred to as colour coated coils due to the variety of colours of organic paint available.

Using hot-dip galvanized steel strip as the substrate for colour coated steel strip provides a dual layer of protection. Besides the zinc layer, the organic coating adds an extra layer of protection, enhancing rust prevention and extending the steel strip's service life by up to 1.5 times compared to regular galvanized strips.

Features:

Color coated coils are steel products that have been coated with organic layers to enhance their appearance and protect against corrosion. This is accomplished by applying one or more layers of paint to the steel surface through a continuous roller coating process, ensuring uniform color and thickness.

The lightweight construction of color coated coils allows for easy handling and installation. Additionally, they are available in various colors, including grey, white, sea blue, and brick red, to meet various design and aesthetic requirements.

The coating on these coils provides excellent protection against corrosion, significantly improving the lifespan of the steel. Furthermore, they can be directly processed, including bending, punching, and cutting, making them versatile and ideal for various applications.

Despite high performance, color coated coils offer a cost-effective solution to many industries, making them an attractive option for those seeking both functionality and affordability.

Key Features
  • Lightweight: Color coated coils are significantly lighter compared to other materials, which makes them easy to handle and install.
  • Aesthetic Appeal: Available in a wide range of colors including grey, white, sea blue, and brick red, they can meet various design and aesthetic requirements.
  • Corrosion Resistance: The coating provides excellent protection against corrosion, extending the lifespan of the steel.
  • Direct Processability: These coils can be directly processed, including bending, punching, and cutting, making them versatile for various applications.
  • Cost-Effective: Despite their high performance, color coated coils are a cost-effective solution for many industries.

Technical Parameters:

The Importance of Coatings for Colour Coated Coils

The selection of coatings for colour coated coils is critical. The chosen coatings are based on the specific environmental conditions in which they will be used, ensuring optimal performance. Different resins are typically used, each offering unique advantages.

Polyester Coatings

Polyester coatings offer good adhesion, rich colours, formability, and outdoor durability at a low cost.

Silicone Modified Polyester (SMP) Coatings

SMP coatings provide good film hardness, abrasion resistance, heat resistance, exterior durability, and resistance to chalking. They also retain gloss well and have general flexibility at a medium cost.

High Durability Polyester (HDP) Coatings

HDP coatings are known for their excellent colour retention, UV resistance, exterior durability, and chalking resistance. They also have good film adhesion, rich colours, and great cost performance.

Polyvinylidene Fluoride (PVDF) Coatings

PVDF coatings are known for their exceptional colour retention, UV resistance, outdoor durability, chalking resistance, solvent resistance, and dirt resistance. They offer good formability but come with a higher cost and are available in limited colours.

Colour coated coils are popular across multiple industries, combining functionality with aesthetic appeal. Coating structures also play a role in determining the performance and application of the coils.

Coating Structures

There are different types of coating structures, each with unique characteristics:

  • 2/1: Coat upper surface twice, lower surface once, bake twice – mainly used for sandwich panels as it has good adhesion. However, its corrosion and scratch resistance is poor.
  • 2/1M: Coat upper and lower surfaces twice, bake once – it has good corrosion resistance, scratch resistance, and moulding properties. It is suitable for single-layer compression moulding panels and sandwich panels.
  • 2/2: Top and bottom surfaces are coated twice each and baked twice – ideal for single-layer pressboards due to its good corrosion resistance, scratch resistance, and processability. However, its adhesion is not good, making it unsuitable for sandwich boards.

The combination of coatings and coating structures gives colour coated coils diversified applications and performance characteristics.

Applications:

Colour Coated Coil Usage

Colour coated coils are preferred for their light weight, aesthetic appeal, and excellent anti-corrosion properties. They come in various colours such as grey, white, sea blue, and brick red, which make them suitable for many applications.

One of the benefits of these coils is their versatility, which makes them the ideal choice for different industries, including advertising, construction, home appliance, electrical appliance, furniture and transport industry.

Advertising

Colour coated coils are used widely in advertising from billboards to signage, and display panels. They provide a perfect way to showcase different products and services since they are appealing to the eye, lightweight and easy to work with.

Construction

Colour coated coils are perfect for roofing, wall cladding, and in manufacturing structural panels in residential and commercial buildings. These coils offer architects and builders more design freedom because they come in an array of colours and also provide excellent anti-corrosion properties that make them durable and long-lasting.

Home Appliance Industry

The home appliance industry relies on colour coated coils for exterior panels of refrigerators, washing machines, and other appliances. These coils offer a variety of colours and finishes that can complement any décor or style.

Electrical Appliances Industry

Colour coated coils are an essential component of various electrical devices. They assist in manufacturing components such as transformers, capacitors, and electronic circuit boards. Their versatility provides the designer the freedom to create attractive and innovative designs.

Furniture Industry

The furniture industry uses colour coated coils to metal furniture in different colours and finishes. This material offers added durability and resistance compared to other traditional materials. This makes them the ideal choice for office, home or outdoor furniture.

Transport Industry

The transport industry relies heavily on colour coated coils for the manufacturing of vehicle bodies and parts. The material used guarantees resistance to harsh weather conditions, bending, and impacts.

0.50*1250 European Market Painted Steel Coils PE paint 10 Years Warranty Z100 Galvanized Color Coated Coil0.50*1250 European Market Painted Steel Coils PE paint 10 Years Warranty Z100 Galvanized Color Coated Coil0.50*1250 European Market Painted Steel Coils PE paint 10 Years Warranty Z100 Galvanized Color Coated Coil

Support and Services:

The Color Coated Steel Coil product is backed by our technical support and services to ensure customer satisfaction. Our team of experts is available to provide assistance with installation, maintenance, and troubleshooting. We also offer training programs to educate customers on the proper use and care of our product. In addition, we provide a warranty for our Color Coated Steel Coil product to protect against any manufacturing defects. Contact us for more information on our technical support and services.

Packing and Shipping:

Product Packaging:

  • The Color Coated Steel Coil will be packed in sturdy, moisture-resistant packaging materials.
  • The packaging will ensure that the product is well-protected during transportation and storage.
  • Each coil will be securely wrapped and labeled with relevant product information.

Shipping:

  • The Color Coated Steel Coil will be shipped via reliable and efficient carrier services.
  • The shipping method will depend on the quantity and destination of the order.
  • Customers will be provided with a tracking number to monitor the progress of their shipment.
