1.3mm Bulk Woven 7628 Fiberglass Cloth Flexible Heat Insulation Roll Engine Exhaust Pipe Covers
1.3mm Bulk Woven 7628 Fiberglass Cloth Flexible Heat Insulation Roll Engine Exhaust Pipe Covers
1.3mm Bulk Woven 7628 Fiberglass Cloth Flexible Heat Insulation Roll Engine Exhaust Pipe Covers
1.3mm Bulk Woven 7628 Fiberglass Cloth Flexible Heat Insulation Roll Engine Exhaust Pipe Covers
Specifications
Brand Name :
SUNTEX
Model Number :
TGF1000-HT
Place of Origin :
China
MOQ :
20 rolls
Payment Terms :
T/T; L/C, Paypal...
Supply Ability :
500000sqm/month
Delivery Time :
5-20 days
Packaging Details :
Each roll in carton, several cartons in a pallet
Application :
Engine Exhaust Pipe Covers
Weight :
1000g/sq.mtr
Working temperature :
550 C
Color :
Brown
Yarn :
Texturized
Treatment :
Heat clean
Description

1.3mm Bulk Woven Fiberglass Cloth Heat Insulation Roll Engine Exhaust Pipe Covers

TGF 1000-HT is a heavy weight woven texturized fiberglass fabric,treated with heat clean.

Texturized fiberglass fabrics are woven by textured E-glass yarns with 9μm and 6μm diameter. Bulk texturing increase the thickness of the fabric to improve the thermal insulation capacity.

This fabric support temperatures to 5500C (10000F). Applications for this fabric includes lagging, padding, removable jacket, thermal insulation covers, stress relief, heavy duty welding blanket and other fire control system.

Technical Data:

PROPERTY DATA
(Metric) (English) Test methods
Weave Plain Plain
Yarn
Warp ET9 860 tex ETG 5.8
Weft ET9 1290 tex ETG 3.87
Construction
Warp 6 ± 0.6 ends/cm 15 ± 1 ends/inch ASTM D 3775-96
Weft 5 ± 0.5 picks/cm 12 ± 1 picks/inch ASTM D 3775-96
Weight 1000 ± 50 g/m2 30 ± 1.5 oz/yd2 ASTM D3776-96
Thickness 1.3 ± 0.1 mm 0.059 ± 0.005 inch ASTM D1777-96
Standard width 101.6 ± 1 cm 40 ± 0.39 inch ASTM D3776-96
152.4 ± 1 cm 60 ± 0.39 inch
182.9 ± 1 cm 72 ± 0.39 inch
Tensile strength
Warp 4300 N/5 cm 491 lbf/inch ASTM D5034-95
Weft 4600 N/5 cm 525 lbf/inch ASTM D5034-95
Temp resistance 5500C 10000F

Key Advantages:

1. Flexible,soft, easy to be fabricated

2. Good tansile strength.

3. Bears temperature 550C degree,800C for short time

Main applications:

1. Removable insulation pads

2. Fabric expansion joints

3. Acoustic insulation
