Specifications
Brand Name :
SUNTEX
Model Number :
GF430P-SI233-1015
Place of Origin :
China
MOQ :
20 rolls
Payment Terms :
T/T; L/C, Paypal...
Supply Ability :
500000sqm/month
Delivery Time :
5-20 days
Packaging Details :
Each roll in carton, several cartons in a pallet
Weight :
15 OZ/y2
Thickness :
0.4 mm
Color :
Silver Grey
Width :
1.55 m
Coating :
Silicon rubber on both side or single side
Standing Temperature :
From -50℃ to 550℃
Coating Weight :
80 g/sqm
Material :
Fiberglass
Origin :
Hubei, China
Description

Best Quality High Silica Fiber Glass Cloth For Welding With Temperature Resistance 2000 F

Description:

This GF430P-SI233-1015 is 3732 fiberglass base cloth which is coated with 150 g/m2 grey silicone coating on two sides. The base fiber glass cloth can withstand 550℃ continuously. While silicone coating can withstand temperature below 260℃.

Silicone coated fiberglass fabric is the most flexible, trackable, and wear resistant fabric. It is made from e-glass woven fiber glass fabric, with properties such as dimensional stability, durability and great tensile strength. Base on silicone coating's properties, this coated fiber glass cloth are always used for fire/welding blanket/curtain, fabric expansion joints/fabric ductwork connector, jacketed vessel insulation covers/exchanger insulation covers and other engineer thermal insulation application.

Parameter List:

BASE FABRIC Base fabric style No. GF430P
(metric) (English) Test methods
Weave 4H Satin Crowfoot
Yarn
Warp EC9 68 1﹡2 ECG 75 1/2
Weft EC9 68 1﹡2 ECG 75 1/2
Construction
Warp 18 ± 1 ends/cm 48 ± 3 ends/inch ASTM D 3775-96
Weft 12.6 ± 1 picks/cm 32 ± 3 picks/inch ASTM D 3775-96
COATED FABRIC Coating style No. SI233-1015
Coating Silicone rubber 2 sides
Weight 510 ± 25 g/m2 15 ± 0.74 oz/yd2 ASTM E84-12
Thickness 0.40± 0.02 mm 0.016 ± 0.0007 inch ASTM E84-12
Color grey
Fire resistance M0
Temp resistance

Glass fabric up to 5500C (10000F)

Silicone rubber coating up to 2500C (4800F)

Main Application:

Fire blanket

Welding blanket

Advantage:

High temp resistant

Water proofing

Excellent non-stick properties

Water and fire protection

Good Chemical Resistance

Superior Flex and Abrasion Resistance

High Silica Fiber Glass Cloth For Welding With Temperature Resistance 2000 F
