Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
Specifications
Brand Name :
SUNTEX
Model Number :
GF200P
Place of Origin :
China
MOQ :
20 rolls
Payment Terms :
T/T; L/C, Paypal...
Supply Ability :
500000sqm/month
Delivery Time :
5-20 days
Packaging Details :
Each roll in carton, several cartons in a pallet
Application :
Heat Tthermocovers
Weight :
6OZ
Working temperature :
1000 F
Performance :
Flame retardant
Color :
Off-white
Raw material :
E-glass
Description

7628 Flame Retardant Fabric Woven Fiberglass Cloth 550C Electronic Heat Insulation

Of all forms of fiberglass textiles, woven fiberglass fabrics offer the widest range and the best control over thickness, weight and strength. This offers the materials engineer a wide choice of controlled fabric properties to satisfy design needs and meet objectives.

GF200P is a light weight woven fiberglass fabric. It’s a premium grade loomstate glass fabric.

USA reference No. 7628.

It is widely used in Electronics, Electrical Appliances, Support Structure, Industrial, Civilian Plate, Basic Fabric For Coating, Model Aircraft, Sports Equipment, Military Industry and Fire Resistance, Filter, Decoration(after special treatment), Packaging and in other field.

GF200P is suitable for coating with difference elastomers and polymers

Technical Data:

PROPERTY DATA
(Metric) (English) Test methods
Weave Plain Plain
Yarn
Warp EC9 68 1﹡0 ECG 75 1/0
Weft EC9 68 1﹡0 ECG 75 1/0
Construction
Warp 17 ± 1 ends/cm 43 ± 3 ends/inch ASTM D 3775-96
Weft 12.4 ± 1 picks/cm 32 ± 3 picks/inch ASTM D 3775-96
Weight 200 ± 10 g/m2 5.88 ± 0.29 oz/yd2 ASTM D3776-96
Thickness 0.19 ± 0.01 mm 0.0074 ± 0.002 inch ASTM D1777-96
Standard width 101.6 ± 1 cm 40 ± 0.39 inch ASTM D3776-96
121.9 ± 1 cm 48 ± 0.39 inch
127 ± 1 cm 50 ± 0.39 inch
Temp resistance 5500C 10000F


Advantages:

  1. Great aggregative, low static/fuzz
  2. Fire resistance, extremely low aberration
  3. Easily wet out by resin
  4. Good mobility in resin
  5. Good physical/chemistry stability

Main applications:

  1. Thermal insulation
  2. Basic cloth for coating
  3. Reinforce plastics and composites
  4. Thermal applications
  5. Aircraft, automobiles
  6. Boat, surfboard building

Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, MoldingFlame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding

Flame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, MoldingFlame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, MoldingFlame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, MoldingFlame Retardant Woven Fiberglass fiber mesh tape is great for Pipe Winding, Seams, Crack, Boat, Molding
