Product Description:

The Electrophoretic Coating Equipment is a versatile product that can handle a wide range of coating types, including the Anodic Electrophoretic Coating System. This system is ideal for use in applications where high corrosion resistance is required. The product is also available in various colors, making it ideal for use in the manufacture of products that require a specific color scheme.

The Electrophoretic Coating Equipment is designed to provide exceptional performance and is customizable to meet the specific needs of the user. The tank size is customizable to ensure that it can accommodate the size of the product being coated. The product can also be adjusted to provide a coating thickness ranging from 5-50 microns, making it ideal for use in applications where precise coating thickness is required.

Overall, the Electrophoretic Coating Equipment is a high-quality product that is ideal for use in a variety of industries. It is a versatile product that can handle a wide range of coating types and is available in various colors. The product is customizable to meet the specific needs of the user and can provide a coating thickness ranging from 5-50 microns. If you are looking for a reliable and effective Electrophoretic Coating Equipment, this product is an excellent choice.

Features:

• Product Name: Electrophoretic Coating Equipment
• Coating Thickness: 5-50 Microns
• Tank Size: Customizable
• Coating Color: Various Colors Available
• Coating Efficiency: 95%
• Coating Method: Dipping
• Keywords: Electrophoretic Deposition Coating Equipment, Anodic Electrophoretic Coating System, Electrophoretic Dip Coating System

Applications:

The Huier Electrophoretic Coating Equipment uses water-based paint as the coating material, making it an eco-friendly and sustainable option for industrial and commercial use. With its electrophoretic coating type, this equipment ensures a high level of coating efficiency of up to 95%.

The dipping coating method employed by the Huier Electrophoretic Coating Equipment makes it suitable for coating a wide range of products, including but not limited to automotive parts, household appliances, metal furniture, and electronic components.

Whether you need an anodic electrophoretic coating system or a cationic electrodeposition coating system, the Huier Electrophoretic Coating Equipment can provide you with the right solution. With various colors available, you can choose the perfect coating color that matches your product's design and specifications.

The Huier Electrophoretic Coating Equipment is perfect for manufacturers and businesses looking for a reliable, efficient, and cost-effective coating system. It can improve the quality of your products while reducing your operational costs.

Investing in the Huier Electrophoretic Coating Equipment is a smart decision that can help you stay ahead of the competition and meet your customers' demands. Contact us today to learn more about this advanced coating system and how it can benefit your business.

Data index:

1. Coating thickness: generally 15 - 30 microns, can be controlled within ±2 microns.

2. Throwing power: the ability to reach the inner cavity of the workpiece, usually expressed as the ratio of the inner cavity film thickness to the outer surface film thickness.

3. Coating utilization rate: up to 95% - 98%.

4. Corrosion resistance: evaluated according to the salt spray test time, such as no rust for more than 500 hours.

5. Production efficiency: a certain number of workpieces that can be processed per hour.

6. Curing temperature: generally 160 - 200℃.

7. Curing time: 20 - 30 minutes.

The paint film thickness is between 15-25μm, and the salt spray resistance can reach 200-800 hours

Function:

1. Gantry structure: provides stable support and a wide range of working space, and can handle multiple or large workpieces at the same time.

2. Electrophoresis system: including electrophoresis tank, DC power supply, stirring device, etc., so that the charged paint particles are deposited on the surface of the workpiece under the action of the electric field to form a uniform coating.

3. Conveying system: through rails, chains or other transmission methods, the workpiece is accurately and smoothly transported to each coating station.

4. Spray cleaning system: spray the workpiece before and after electrophoresis to remove surface impurities and residual paint.

5. Ultrafiltration recovery system: recover solvents and small molecules in electrophoretic paint, improve the utilization rate of paint, and maintain the stability of electrophoretic paint.

6. Drying and curing system: heating is used to quickly cure the electrophoretic coating to form a strong and durable paint film.

7. Automated control system: accurately control the entire coating process, including the setting and monitoring of parameters such as temperature, voltage, time, and speed.

The gantry electrophoretic coating automatic equipment assembly line is an automated production line designed for electrophoretic coating process, especially suitable for mass production that requires high-quality surface treatment. The characteristic of this assembly line is that it adopts a gantry structure, where "gantry" refers to a large support structure similar to the shape of a door frame, which is used to support and guide the crane or hoist that transports the workpiece to move above the coating area, realizing the automatic transmission of the workpiece between different treatment tanks.
