РК75-3-32 CCTV Run Lengths 75 Ohm Security Camera With Coaxial Cable , Long Life
РК75-3-32 CCTV Run Lengths 75 Ohm Security Camera With Coaxial Cable , Long Life
РК75-3-32 CCTV Run Lengths 75 Ohm Security Camera With Coaxial Cable , Long Life
РК75-3-32 CCTV Run Lengths 75 Ohm Security Camera With Coaxial Cable , Long Life
РК75-3-32 CCTV Run Lengths 75 Ohm Security Camera With Coaxial Cable , Long Life
РК75-3-32 CCTV Run Lengths 75 Ohm Security Camera With Coaxial Cable , Long Life
Specifications
Brand Name :
hellosignal
Model Number :
PK75
Certification :
UL, ETL, CE,CPR, RoHS
Place of Origin :
CHINA
MOQ :
30 KM
Price :
HANGZHOU ZION COMMUNICATION CO.,LTD
Payment Terms :
T/T, L/C, D/P
Supply Ability :
3000KM / Month
Delivery Time :
Normally 25 working days
Packaging Details :
pull box, wooden spool, carton, pallet
Conductor :
CU
Dielectric :
FPE
Shield :
CCAM
Jacket :
PVC
Description

CCTV CABLE PRODUCTS CATEGORY

https://www.zion-communication.com/cctv-coaxial-cable-products-catalog.html

РК75-3-32

75 Ohm CCTV coaxial Cable

NO.7100365
Construction Parameters:
Inner Conductor 0.024"/0.60mm/22 AWG CU
Dielectric 0.144"/2.70mm FPE
Shield 96/ 0.12mm CCAM
Jacket 4.4mmPVC
Jacket Thickness 0.032"/0.81mm
Application For Use in Longer CCTV Run Lengths
Electrical Characteristics:
Inner Conductor Resistance The Max. at 20℃ shall be < 63Ω/km
Capacitance 56.5±1 pF/m
Impedance 75±5 Ω
Return loss between 5 and 1000MHz: > 20dB
Velocity of Propagation 0.82
Sparker Test (VAC)
Mechanical and Envrionmental Properties
Cable bend radius 10 times the cable diameter
Operating Temp Range -20 ℃ to 60℃
Cable diamensions 0.130"±0.006"/3.30±0.30mm PVC
Cross Section
РК75-3-32 CCTV Run Lengths 75 Ohm Security Camera With Coaxial Cable , Long Life
Attenuation(20℃):
Frequency (MHZ) Max Attenuation(dB/100m)
10 3.54
50 8.04
200 16.50
470 25.80
862 35.80
1000 39.00
1350 46.10
1750 53.50
2150 60.00
2400 64.50
Order Informations:
Marking

HELLOSIGNAL РК75-3-32

CCTV COAXIAL CABLE 7100365 ×××M/FT
Package Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …
Delivery time Normally 25 days after received the deposit.
Brand HELLOSIGNAL® OR OEM
