BC Conductor PK75-2-110 Cctv Camera Coaxial Cable Copper Clad Aluminum Shield
BC Conductor PK75-2-110 Cctv Camera Coaxial Cable Copper Clad Aluminum Shield
BC Conductor PK75-2-110 Cctv Camera Coaxial Cable Copper Clad Aluminum Shield
BC Conductor PK75-2-110 Cctv Camera Coaxial Cable Copper Clad Aluminum Shield
BC Conductor PK75-2-110 Cctv Camera Coaxial Cable Copper Clad Aluminum Shield
BC Conductor PK75-2-110 Cctv Camera Coaxial Cable Copper Clad Aluminum Shield
BC Conductor PK75-2-110 Cctv Camera Coaxial Cable Copper Clad Aluminum Shield
BC Conductor PK75-2-110 Cctv Camera Coaxial Cable Copper Clad Aluminum Shield
Specifications
Brand Name :
hellosignal
Model Number :
PK75
Certification :
UL, ETL, CE,CPR, RoHS
Place of Origin :
CHINA
MOQ :
30 KM
Price :
HANGZHOU ZION COMMUNICATION CO.,LTD
Payment Terms :
T/T, L/C, D/P
Supply Ability :
3000KM / Month
Delivery Time :
Normally 25 working days
Packaging Details :
pull box, wooden spool, carton, pallet
Conductor :
BC
Dielectric :
Solid PE
Shield :
Copper clad aluminum
Jacket :
PVC
Description

CCTV CABLE PRODUCTS CATEGORY

https://www.zion-communication.com/cctv-coaxial-cable-products-catalog.html

PK75-2-110 BC 40% CCA PVC

75 Ohm CCTV coaxial Cable

NO.7100303
Construction Parameters:
Inner Conductor 0.014"/0.37mm/28 AWG BC
Dielectric 0.144"/2.2mm Solid PE
Shield Copper clad aluminum
braid wire 40% coverage
Jacket 0.130"±0.006"/3.30±0.30mm PVC
Jacket Thickness 0.032"/0.81mm
Application For Use in Longer CCTV Run Lengths
Electrical Characteristics:
Inner Conductor Resistance The Max. at 20c℃ shall be < 168.2 Ω/km
Capacitance 68±1 pF/m
Impedance 75±5 Ω
Return loss 20dB
Velocity of Propagation
Sparker Test (VAC)
Mechanical and Envrionmental Properties
Cable bend radius 10 times the cable diameter
Operating Temp Range -20 ℃ to 60℃
Cable diamensions 0.130"±0.006"/3.30±0.30mm PVC
Cross Section
BC Conductor PK75-2-110 Cctv Camera Coaxial Cable Copper Clad Aluminum Shield
Attenuation(20℃):
Frequency (MHZ) Max Attenuation(dB/100m)
10 5.86
50 13.50
200 30.80
470 47.50
862 73.00
1000
1350
1750
Order Information:
Marking

HELLOSIGNAL PK75-2-110 BC 40% CCA PVC

CCTV COAXIAL CABLE 7100303 ×××M/FT
Package Inquired Length on Reel, Pull Box, Plastic Spool, wooden Spool, pallet …
Delivery time Normally 25 days after received the deposit.
Brand HELLOSIGNAL® OR OEM
