PK75-3-316 нг( А ) - HF BC 65% TCCA LSZH Coax Cable For Security Cameras
PK75-3-316 нг( А ) - HF BC 65% TCCA LSZH Coax Cable For Security Cameras
PK75-3-316 нг( А ) - HF BC 65% TCCA LSZH Coax Cable For Security Cameras
PK75-3-316 нг( А ) - HF BC 65% TCCA LSZH Coax Cable For Security Cameras
PK75-3-316 нг( А ) - HF BC 65% TCCA LSZH Coax Cable For Security Cameras
PK75-3-316 нг( А ) - HF BC 65% TCCA LSZH Coax Cable For Security Cameras
PK75-3-316 нг( А ) - HF BC 65% TCCA LSZH Coax Cable For Security Cameras
PK75-3-316 нг( А ) - HF BC 65% TCCA LSZH Coax Cable For Security Cameras
Specifications
Brand Name :
hellosignal
Model Number :
PK75
Certification :
UL, ETL, CE,CPR, RoHS
Place of Origin :
CHINA
MOQ :
30 KM
Price :
HANGZHOU ZION COMMUNICATION CO.,LTD
Payment Terms :
T/T, L/C, D/P
Supply Ability :
3000KM / Month
Delivery Time :
Normally 25 working days
Packaging Details :
pull box, wooden spool, carton, pallet
Conductor :
BC
Dielectric :
Solid PE
Shield :
Copper clad aluminum
Jacket :
PVC
Description

CCTV CABLE PRODUCTS CATEGORY

https://www.zion-communication.com/cctv-coaxial-cable-products-catalog.html

PK75-3-316 нг(А)-HF BC 65% TCCA LSZH

75 Ohm CCTV coaxial Cable

NO.7100355
Construction Parameters:
Inner Conductor 7* 0.008"/7* 0.2mm/7* 32 AWG BC
Dielectric 0.144"/2.70mm FPE
Shield 1 Al/PET Foil
Shield 2 0.12mmTCCA(65%)
Jacket 0.170"±0.006"/4.50±0.30mmLSZH
Jacket Thickness 0.032"/0.81mm
Application For Use in Longer CCTV Run Lengths
Electrical Characteristics:
Inner Conductor Resistance The Max. at 20c shall be < 63 Ω/km
Capacitance 56.5±1 pF/m
Impedance 75±5 Ω
Return loss between 5 and 1000MHz: > 20dB
Velocity of Propagation 0.82
Sparker Test (VAC)
Mechanical and Envrionmental Properties
Cable bend radius 10 times the cable diameter
Operating Temp Range -20 ℃ to 60℃
Cable diamensions 0.130"±0.006"/3.30±0.30mm LSZH
Cross Section
PK75-3-316 нг( А ) - HF BC 65% TCCA LSZH Coax Cable For Security Cameras
Attenuation(20℃):
Frequency (MHZ) Max Attenuation(dB/100m)
10 3.36
50 7.05
200 14.30
470 22.50
862 30.30
1000 32.80
1350 39.40
1750 45.20
2150 50.40
2400 53.50
Order Informations:
Marking

HELLOSIGNAL PK75-3-316 нг(А)-HF BC 65% TCCA LSZH

CCTV COAXIAL CABLE 7100355 ×××M/FT
Package Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …
Delivery time Normally 25 days after received the deposit.
Brand HELLOSIGNAL® OR OEM
