3C-2VS Coaxial Cable Inner Conductor BC JIS C Series Coaxial Wholesale 3C-2VS Video Cable Best Price CCTV Cable
3C-2VS Coaxial Cable Inner Conductor BC JIS C Series Coaxial Wholesale 3C-2VS Video Cable Best Price CCTV Cable
Specifications
Brand Name :
Zion communication OR OEM
Model Number :
JIS C CCTV Coaxial Cable
Certification :
ISO, UL, CE, RoHS
Place of Origin :
China
MOQ :
30 KM
Payment Terms :
T/T, L/C
Supply Ability :
3000KM / Month
Delivery Time :
25 working days
Packaging Details :
305M, 1000FT, Wooden Reel, Carton
Conductor :
BC
Insulation :
SPE
Shield :
6×25 BC Braid(L=26)
Jacket :
PVC
Color :
Black, White
Package :
305M, 1000FT, Wooden Reel, Carton
Description

3C-2VS

75 Ohm CCTV coaxial Cable

NO.7100905
Construction Parameters:
Inner Conductor 7×0.18mmBC
Dielectric 3.1mm SPE
Shield 0.14mm×6×25 BC Braid(L=26)
Jacket 5.4±0.5mmPVC
Jacket Thickness 0.08mm
Application For Use in Longer CCTV Run Lengths
Electrical Characteristics:
Inner Conductor Resistance The Max. at 20℃ shall be<100Ω/km
Capacitance 67±3 pF/m
Impedance 75 ± 3 Ω
Return loss between 5 and 1000MHz: > 20dB
Velocity of Propagation
Sparker Test (VAC) 1
Mechanical and Envrionmental Properties
Cable bend radius 10 times the cable diameter
Operating Temp Range -20 ℃ to 65℃
Cable diamensions
Cross Section
3C-2VS Coaxial Cable Inner Conductor BC JIS C Series Coaxial Wholesale 3C-2VS Video Cable Best Price CCTV Cable
Attenuation(20℃):
Frequency (MHZ) Max Attenuation(dB/100ft) Max Attenuation (dB/100m)
10 4.20
30 7.30
72 11.30
88 12.50
90 12.60
135 15.40
180 17.80
220 19.70
270 21.80
440 27.90
750 36.40
770 36.90
Order Informations:
Marking

HELLOSIGNAL 3C-2VS

CCTV COAXIAL CABLE 7100905 ×××M/FT
Package Inquired Length on Reel,Pull Box,Plastic Spool,wooden Spool,pallet …
Delivery time Normally 25 days after received the deposit.
Brand HELLOSIGNAL® OR OEM
