7241002 CAT.5e U/UTP RJ45 Patch Cord Patch Cable

Application:

• Purpose: Designed for use in high-speed network environments like data centers, supporting up to 1GBASE-T (Gigabit Ethernet).
• Compliance: Meets various standards such as ANSI/TIA/EIA-568.2-D, ISO/IEC 11801, IEEE, and CENELEC EN50173 for Category 5e cabling.

Technical Specifications:

• Conductor: Stranded bare copper.
• Pairs: 4 twisted pairs.
• Insulation: High-Density Polyethylene (HDPE).
• Insulation Colors:
  • Orange/White-Orange
  • Blue/White-Blue
  • Green/White-Green
  • Brown/White-Brown
• Pair Shielding: Aluminum/PET foil (100% coverage), aluminum face outwards.
• Outer Jacket: Available in LSZH (Low Smoke Zero Halogen) or PVC.
• Frequency Range: 1-100 MHz.
• Impedance: 100Ω.
• Max. Resistance Unbalance: 2%.
• Current Rating: 1.5A.
• Max Voltage: 72 VDC.
• Operating Temperature: -20°C to +60°C.

Connector Details:

• Plug Material: Polycarbonate.
• Type: RJ45.
• Boot Material: LSZH or PVC (snagless design).
• Contact Material: Phosphor bronze with 50µ” gold over nickel plating.
• Shielding: Copper alloy, nickel-plated.
• Durability: 750 mating cycles minimum.

Performance Characteristics:

• Category: Cat 5e.
• Max. Operating Frequency: 100 MHz.
• Shielding Type: U/UTP (Unshielded Twisted Pair).
• Primary Usage: Gigabit Ethernet (1GBase-T), ideal for high-speed data transfer in data centers, network devices, routers, and patch panels.
• Special Notes: Suitable for lengths up to 100 meters.

OEM/ODM Services:

ZION Communication offers OEM/ODM services, which include:

• Custom logos on plugs and boots.
• Printing on cables.
• Custom labeling on packaging (e.g., PE bags or cartons).
• Available in different colors and lengths.
• Custom molding/strain relief options.
