1/2 Super Flex Jumper Cable 4.3/10 Male to 4.3/10 Male
1/2 Super Flex Jumper Cable 4.3/10 Male to 4.3/10 Male
Specifications
Brand Name :
Zion communication OR OEM
Model Number :
Super Flex Jumper Cable
Certification :
UL, ETL, CE,CPR, RoHS
Place of Origin :
China
MOQ :
10 KM
Payment Terms :
T/T, L/C
Supply Ability :
1000KM / Month
Delivery Time :
25 working days
Packaging Details :
100M, 300M, Wooden Reel, Carton
Characteristic Impedance :
50 ohm
Dielectric Resistance :
≥5000MΩ
name :
1/2" Super Flex Jumper Cable 4.3/10 Male to 4.3/10 Male
keyword :
flex jumper cable
Description
1/2" Superflex Jumper,
4.3/10 Male Straight to 4.3/10 Male Straight
No.71011105A4B4MS
Cross Section:
1/2
Interface:
According to IEC 61169-54
Electrical:
Characteristic Impedance 50 ohm
Freqency Range DC-4GHz
VSWR ≤1.12(0-3GHz)
≤1.15(0-4GHz)
PIM (@2-tonex20w) ≤-160dBc
Dielectric Withstanding Voltage ≥2500V RMS,50Hz,at sea level
Dielectric Resistance ≥5000MΩ
Contact Resistance Center Contact ≤1.0mΩ
Outer Contact ≤1.0mΩ
Mechanical:
Durability Mating cycles ≥100 cycles
Material and plating:
Material Plating
Body Brass Tri-alloy
Insulator PTFE -
Center conductor Phosphor bronze/Brass Ag
Others Brass Ni
Environmental:
RoHS-compliance Full RoHS compliance
Temperature Range -60℃～+85℃
Watertightness IP6
Salt-fog test 96h
