Flip-chip Led Light Module 30 watt RGBW Color-Mixing LEDs Anti-poisonous
Flip-chip Led Light Module 30 watt RGBW Color-Mixing LEDs Anti-poisonous
Specifications
Brand Name :
TYANSHINE
Model Number :
TX-1818RGBW30FC120-NUVCNG-01
Certification :
ISO9001:2008 SGS RoHS
Place of Origin :
CN
MOQ :
1pc
Price :
USD
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
5000pcs / Month
Packaging Details :
In Plastic Tray
Power :
30W
Vf :
3.2-4.0V
If :
1800mA
Color :
RGBW Color-Mixing
Luminous Flux :
780lm-900lm
Viewing Angle :
120 degree
Description

Flip-chip Led Light Module 30 watt RGBW Color-Mixing LEDs Anti-poisonous

Features for 30W RGBW LEDs:

1, Small LES, High Light Density 5W/mm² ;

2, Flip-chip Eutectic-bonding, fast heat-conductivity;

3, Higher performance of RGBW 4IN1 Color-Mixing;

4, Anti-poisonous or toxic, comply with RoHS

Specifications:

Code Color

Vf

(V)

If

(mA)

RθJ-C

Φv

(lm)

 Power

LES

(mm)
TX-1818RGBW30FC120-NUVCNG-01 RGBW 3.2-4.0 1800 0.75 K/W 780-900 30 9 x 9

Characteristics at If=1800mA (Ta=85°C)

Parameter Symbol Emitting
Color		 Values
Min. Typ. Max.
Luminous Flux φv R 190lm 220lm -
G 210lm 230lm -
B 55lm 65lm -
W 330lm 360lm -
Dominant Wavelength λd R 615nm 620nm 625nm
G 515nm 520nm 525nm
B 452nm 456nm 460nm
Colour Temperature CCT W 6500K 7500K 8500K
Forward Voltage Vf R 2.4V 2.8V 3.2V
G 3.2V 3.6V 4.0V
B 3.2V 3.6V 4.0V
W 3.2V 3.6V 4.0V

Applications:

Entertainment lighting, Projection lights, Moving-Heads, SPOT, GOBO

Architectural lighting

Medical lighting

Event lighting

Stage lighting Projection

Fiber optic lighting
