High CRI 90 COB Full Spectrum White Led Array 150W 250W for Broadcast / Photography
High CRI 90 COB Full Spectrum White Led Array 150W 250W for Broadcast / Photography
Specifications
Place of Origin :
CN
Brand Name :
TYANSHINE
Certification :
ISO9001:2008 SGS RoHS
Model Number :
TX-6060W250D180CUY-B01H90
MOQ :
10pcs
Price :
negotiation
Packaging Details :
In Tray
Delivery Time :
5-10 days
Payment Terms :
T/T
Supply Ability :
10,000pcs/week
Description

High CRI 90 COB Full Spectrum White Led Array 150W 250W for Broadcast / Photography

High CRI LED White COB Array 150W 250W 400W to Upgrade Tungsten Fresnels


Features:

  1. High CRI, better performance, 95Ra Warm white 3200K, 90Ra Daylight 5600K
  2. High power/high efficiency package
  3. Full spectrum White Color-mixing by RGBY
  4. Integraged packages, low luminous decay and long lifespan
  5. 3mm Copper MCPCB, fast heat-conductivity
  6. Easy installation, cost-saving


Specifications:

Code Color

Vf (V)

If (A)

 λd(nm)
CCT(K)

φv (lm)

Power (W)

LES (mm)

 CRI (Ra)
TX-3840WYS120D180CUY-001 White 28-33 1.4 6500-7500 2700-2900 120W Φ26 ≥90
Yellow 28-33 1.2 589-595 1000-1300
Warm White 28-33 1.4 3000-3300 2300-2500
TX-3840WS150D180CUY-001 White 28-32 2.5 6500-7500 3700-3900 150W Φ26 ≥90
Warm White 28-32 2.5 3000-3300 2900-3100
TX-3840W150D180CUY-C01H95 Warm White 28-33 5 3200 ± 200K 9500-11000 150W Φ26 ≥97
TX-3840W150D180CUY-B01H90 White 28-33 5 5600 ± 200K 11000-12500 150W ≥90
TX-6060W250D180CUY-C01H95 Warm White 28-33 5-8 3200 ± 200K 10000-18000 250W Φ37 ≥97
TX-6060W250D180CUY-B01H90 White 28-33 5-8 5600 ± 200K 12000-20000 250W ≥90
TX-7076W400D180CUY-C01H95 Warm White 42-48 6.5-8.5 3200 ± 200K 20000-28000 400W Φ52 ≥97
TX-7076W400D180CUY-B01H90 White 42-48 6.5-8.5 5600 ± 200K 24000-32000 400W ≥90


Remarks:
Available 3 channels White / Yellow / WarmWhite 60W / 120W
and 3 Colours White / Red / WarmWhite.


Package Dimension:





Applications:

Broadcast / Photography / TV / Film equipment luminaires

LED Fresnels light

Entertainment stage / studio lighting

Architectural lighting



(the image for reference only)
