CCT 7000K 150W White Led Chip For Medical Illumination Units
CCT 7000K 150W White Led Chip For Medical Illumination Units
CCT 7000K 150W White Led Chip For Medical Illumination Units
CCT 7000K 150W White Led Chip For Medical Illumination Units
Specifications
Place of Origin :
CN
Brand Name :
TYANSHINE
Certification :
ISO9001:2008 SGS RoHS
Model Number :
TX-3636W150FC120-NUVENG-A01
MOQ :
10pcs
Price :
Negotiation
Packaging Details :
In Tray
Delivery Time :
5-10 days
Payment Terms :
ExW
Supply Ability :
10000pcs/week
CCT :
7000K
Power :
150W
Chip Brand :
CREE
Efficiency :
45lm/W
Description

CCT 7000K 150W White Led Chip For Medical Illumination Units

Features & Advangates:

1, Small LES, 5W/mm²

2, Eutectic packages, Thermoelectric management, fast heat-conductivity

3, Special Parallel and Serial connection, Low If, higher Vf

4, Average efficiency upto 40lm/W @Tj=85℃ with full power

5, Excellent effect of color-mixing for 3Colors or 4Colors LEDs light source

6, Quick on/off; Anti-poisonous or toxic, comply with RoHS

Specifications:

Code Color

Vf

(V)

If

(A)

CCT(K)

Φv

(lm)

 Power

LES

(mm)
TX-3636W90FC120
-NUVENG-A01		 White 12-16 6.5 6500-8500 3600-4000 90 4.3 x 4.3
TX-3636W150FC120
-NUVENG-A01		 White 12-16 11 6500-8500 6000-6500 150 6.5 x 6.5

Applications:

Entertainment lighting

Architectural lighting

Medical illumination, Fiber Optics

Event lighting

Stage lighting Projection
