Flip-chip White LED Diode 60 W High Lumen LED Emitter with High Light Density
Flip-chip White LED Diode 60 W High Lumen LED Emitter with High Light Density
Specifications
Brand Name :
TYANSHINE
Model Number :
TX-1818W60FC120-CUHCNG-A01
Certification :
ISO9001:2008 SGS RoHS
Place of Origin :
CN
MOQ :
10pcs
Supply Ability :
5000pcs/Month
Packaging Details :
In Tray
Chip :
Cree flip-chip
Power :
60Watt
VF :
28-32V
IF :
2.2A
Lumen :
4400-4800lm
CCT :
6000K-8000K
LES :
9x9mm
Description

Flip-chip White LED Diode 60 W High Lumen LED Emitter with High Light Density

Brief Introduction of LED Modules:

  1. High Brightness with CREE Flip-chip LEDs, Quality assured LED Components for Entertainment Lighting products;
  2. Eutectic bonding to make sure the fast conductivity of heat, it's aim to the lumen maintenance;
  3. Small Light Emiting surface(LES) to enhance the light density;
  4. Using copper MCPCB to carry the LED chips, the LEDs can be installed directly to the heat sinks.

Specifications:

Absolute Maximum Ratings at Ta=85℃

Item Code

TX-1818W60FC120-CUHCNG-A01
Parameter Symbol Value Unit
LED Junction Temperature Tj 150 ℃
Power Dissipation PD 60 W
Continuous Forward Current IF 2.2 A
ElectrostaticDischarge Threshoid ESD 2000 V

Characteristics at If= 2.2A (Ta=85°C):

Parameter Symbol Values Units
Min. Typical Max.
Luminous Flux φV 4400 4800 - lm
Viewing Angle at 50﹪IV 2θ1/2 - 120 - degree
Forward Voltage Vf 28 30 32 V
Correlated Colour Temperature CCT 6500 7500 8500 K
Thermal Resistance Junction to Case RθJ-C - 0.2 - K/W

Package Dimensions:

Flip-chip White LED Diode 60 W High Lumen LED Emitter with High Light Density

Applications:

Entertainment Lighting - LED Moveing-Heads Beam & Spot washing

Architectural illumination

Medical illumination

Flip-chip White LED Diode 60 W High Lumen LED Emitter with High Light Density
