Color Tunning White Multichip LED , 3000K - 6000K 2700LM 60W LED Emitter
Color Tunning White Multichip LED , 3000K - 6000K 2700LM 60W LED Emitter
Color Tunning White Multichip LED , 3000K - 6000K 2700LM 60W LED Emitter
Color Tunning White Multichip LED , 3000K - 6000K 2700LM 60W LED Emitter
Color Tunning White Multichip LED , 3000K - 6000K 2700LM 60W LED Emitter
Color Tunning White Multichip LED , 3000K - 6000K 2700LM 60W LED Emitter
Color Tunning White Multichip LED , 3000K - 6000K 2700LM 60W LED Emitter
Color Tunning White Multichip LED , 3000K - 6000K 2700LM 60W LED Emitter
Specifications
Brand Name :
TYANSHINE
Model Number :
TX-1818WS600FC120-CUHCNG-01H90
Certification :
ISO9001:2008 ROHS SGS
Place of Origin :
CN
MOQ :
10
Payment Terms :
Western Union, T/T, L/C
Packaging Details :
In tray
Color-mixing :
VariWhite 3000K-6000K
Forward Voltage :
3V-4V
Power :
60W
LES :
Φ11
Efficiency :
40lm/W
CRI :
90Ra
Lumen :
2300lm-2700lm
Description

Color Tunning White Multichip LED , 3000K - 6000K 2700LM 60W LED Emitter

Features for 60W VariWhite LEDs:

1, Small LES, 5W/mm² , high brightness and light density. To generate strong light beam

2, Eutectic packages technique,compact light source, fast heat-conductivity, low thermal resistance

3, Special Parallel and Serial connection,1/4 current for the same power compared with Luminus CBT-90;

4, Average efficiency upto 40lm/W @Tj=85℃ with full power;

5, Multi chip on board technology, using 3mm Copper substrate to absorb heat immediately,

Specifications:

Code Color

Vf

(V)

If

(mA)

RθJ-C

Φv

(lm)

 Power

LES

(mm)
TX-1818WS600FC120-CUHCNG-01H90 WS 3.5-4.2V 3000 0.75 K/W 2300-2700 60 9 x 9

Characteristics at If=1800mA (Ta=85°C)

Parameter Symbol Emitting
Color		 Values
Min. Typ. Max.
Luminous Flux φv W 650lm 750lm -
S 500lm 600lm -
W 650lm 750lm -
S 500lm 600lm -
Colour Temperature CCT W 5300K - 5800K
S 3000K - 3250K
Forward Voltage Vf 3.5V - 4.2V

Color Tunning White Multichip LED , 3000K - 6000K 2700LM 60W LED Emitter

Applications:

Film / Studio lighitng

Entertainment lighting, Projection lights

Architectural lighting

Medical lighting

Event lighting

Stage lighting Projection

Fiber optic lighting
