Specifications
Brand Name :
ADLED
Model Number :
ADS-YCOB-336
Certification :
UL/CE/RoHS
Place of Origin :
China
MOQ :
100M
Payment Terms :
T/T, Western Union, L/C, D/A, D/P, MoneyGram
Supply Ability :
100000M
Delivery Time :
7days
Packaging Details :
5m(16.4ft) Per Roll
Name :
Economical 336Chips/m COB LED Tape Light
Model :
ADS-YCOB-336
Voltage :
DC12V/24V
LEDs Per Metre :
336
Watts Per Metre :
8W
Colour Temperature :
3000K/4000K/6500K/Red/Green/Blue/Yellow
IP Rating :
IP20/IP65/IP67/IP68
Beam Angle :
180°
Warranty :
3 Years
PCB Width :
8mm
Description

Economical Outdoor LED Flexible Light Strips 3000K 4000K 6500K


Benefits of COB LED Strip Light

1. Chip On Board LED Strip
Hot spot lights of traditional
high density LED strip are bad for eyes, dotless LED strip lights emit uniform brightness, shines in one straight line, it emits perfect lighting even without LED aluminum profile.
Economical Outdoor LED Flexible Light Strips 3000K 4000K 6500K

2. More Bendable LED Strip
Usually hundreds of chips combines in one meter of
COB LED light strip, the space between two chips is ultra narrow, you can bend arbitrarily COB LED strip light without any damages.
Economical Outdoor LED Flexible Light Strips 3000K 4000K 6500K

3. Brightest of COB LED Strips

ADLED wholesale
COB light strips up to 100LM/W is more bright than SMD LED light strips in room.

4. 180° Beam Angle
New LED COB
light strips emit 180 degree beam angle, traditional flexible LED lighting strips emit only 120 degree. More wide view to create a more uniform brightnss of dimmable LED strip light.

Economical Outdoor LED Flexible Light Strips 3000K 4000K 6500K

5.Types of Chip on Board LED Strip

The high density LED strips of ADLED have single strip LED light, mini cuttable LED strips, small LED strip lights, 5v dc LED strip, dual LED strip, RGB strip lighting and RGBW LED strips.

Economical Outdoor LED Flexible Light Strips 3000K 4000K 6500K


COB LED Tape Light Manufacturers


ADLED is one of Top-tier
dotless LED tape manufacturers in China. Our R&D team develop 3 new style LED strip lights each month. You can get different pattern LED light strip for indoor and outdoor application.

All our flexible strip lighting are of UL, CE, RoHS certified products, guarantee 2 or 5 years warranty.

Economical Outdoor LED Flexible Light Strips 3000K 4000K 6500K


What is COB LED Strip Lights without dots?
COB lighting strip means directly package chips on the circuit board (PCB), then drop a layer of glue mixed with phosphor powder on the surface of chips.

Manufacturing no dot LED strip eliminates the wire bonding process of SMD chips and soldering brackets compared with
LED strip no dots production, it greatly improved the stability of the product and better heat dissipation.
Economical Outdoor LED Flexible Light Strips 3000K 4000K 6500K

COB LED Strip Specifications:

Model ADS-YCOB-336
LED type COB (Chip On Board)
LEDs per metre 336
Operating voltage DC12V/24V
Watts per metre 8W
Colour temperature 2700K/3000K/4000K/5000K/6500K/Red/Green/Blue/Yellow
IP rating P20/IP65/IP67/IP68
PCB width 8mm
Cut points 35.71mm(1.41'') for 12V; 62.5mm(2.46'') for 24V
Beam angle 180°
Warranty 3 Years
Certifications UL/CE/RoHS/ErP
Package 5m(16.4ft) per roll
Dimmable

0-100% dimmable by LED strip light dimmer

Economical Outdoor LED Flexible Light Strips 3000K 4000K 6500K

Economical Outdoor LED Flexible Light Strips 3000K 4000K 6500K


COB LED Strip Application:

General Ambient Lighting • Under Shelving Lighting
• Stage Lighting • Art Lighting
• Edge Lighting • Motorcycles Lighting
• Under Motorcycles • Ceiling Lighting
• Outdoor Lighting • Architectural Displays Lighting
• Kitchen Counter Lighting • Mirror backLighting
• Cabinets Lighting • Decorative Lighting
• Gardens Lighting • Linear Lighting
• Boats Lighting • Mirror Lighting


Economical Outdoor LED Flexible Light Strips 3000K 4000K 6500K

COB LED Strip FAQ:
Q:
Why more and more people choose COB LED tape?
COB LED tape has many big advantages compared with SMD LED strip, such as perfect linear lighting effect, more flexibility, etc. With advanced craft, it can produce more perfect CRI and color temperature values.


Q: Can you link LED strip lights?
Yes, you can link LED strip lights easily. We can provide lots of LED strip accessory, 10mm LED strip connector, 8mm LED strip connector for 528chips COB LED strip.


Q: Is COB LED strip dimmable ?
Yes, you can dim these dimmable COB LED strip with a simple LED dimmer.


Q: Can you make waterproof COB LED strip?
Yes, we can make waterproof COB LED strip IP65, IP67, IP68 for different lighting applications.


Q: Do COB LED strip need aluminum profile for heat dissipation?
Yes, LED aluminum profile can help COB light strip to dissipate heat better and prolong the life of the COB light strip.
