1.2Ghz 7000mW Wireless Analog Video Transmitter with 12V DC for FPV and Drones
1.2Ghz 7000mW Wireless Analog Video Transmitter with 12V DC for FPV and Drones
1.2Ghz 7000mW Wireless Analog Video Transmitter with 12V DC for FPV and Drones
1.2Ghz 7000mW Wireless Analog Video Transmitter with 12V DC for FPV and Drones
1.2Ghz 7000mW Wireless Analog Video Transmitter with 12V DC for FPV and Drones
1.2Ghz 7000mW Wireless Analog Video Transmitter with 12V DC for FPV and Drones
Specifications
Brand Name :
Kimpok Technology
Model Number :
KP-MINIA7
Certification :
CE/FCC/ROHS
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T, Western Union,PayPal
Supply Ability :
100 PCS Per Month
Delivery Time :
3-7 days
Packaging Details :
Export Standard Packing
Frequency :
1.2Ghz
Number of channels :
4 CHs
Transmit Power :
7000mW
Voltage :
DC 12V
Weight :
100g
Transmit Distance :
3-6km on ground; up to 20km from air to ground
Description

1.2Ghz 7W Wireless Analog Video Transmitter with 12V DC for FPV and Drones

FPV Drones Features:

1. Wireless transmission: no need to set up communications cable
2. Image, audio sync, color black and white compatible
3. Small size, light weight, easy to carry, good installation
4. Responsive, timely, send and receive real-time transmission
5. Using FM mode, anti-interference ability, good image quality
6. Highly integrated, stable and reliable transmission distance
7. DC power supply, easy to use.
8. Large output frequency, equipped fan in it, credibility, use for long distance wireless transmit projects and special use in military project.

Transmitter parameter:

Output 7000mW
Current Consumption 1.5A
Frequency 1.2Ghz
Channel 4CH
Band 1080 MHz, 1120 MHz, 1160 MHz, 1200 Mhz
Output impedance 50 Ohm
Audio input impedance 1k Ohm
Audio input amplitude 1.2Vp-p
Video input impedance 75 Ohm
Video input amplitude 1.2Vp-p
Voltage DC 12V(at 36dbm)
Working current 700mA
The lowest Voltage DC 5V(at 31dbm)
Weight 100g
Size 74*56*36mm
Accessories transmitter, antenna, Tx cable

Receiver parameter:

Frequency 1.2Ghz
Channel 12CH
Working voltage DC 12V
Current consumption 260mA
Weight 115g
Size 115*80*21mm
Accressories receiver, antenna, AV cable

Pictures:

1.2Ghz 7000mW Wireless Analog Video Transmitter with 12V DC for FPV and Drones

1.2Ghz 7000mW Wireless Analog Video Transmitter with 12V DC for FPV and Drones

1.2Ghz 7000mW Wireless Analog Video Transmitter with 12V DC for FPV and Drones

1.2Ghz 7000mW Wireless Analog Video Transmitter with 12V DC for FPV and Drones

1.2Ghz 7000mW Wireless Analog Video Transmitter with 12V DC for FPV and Drones

1.2Ghz 7000mW Wireless Analog Video Transmitter with 12V DC for FPV and Drones

Our Service:

1. One-stop ODM/OEM solution;
2. 24-hour technical support;
3. Lifetime maintenance (Replacement parts will be charged after a year);
4. Provide professional system design and construction;
5. You will get good price and high quality here since we are an experienced manufacturer in wireless microwave transmission area since 1998, we are the source.

Whatever your wireless surveillance application or budget, we can find the right solution for you.

Contact us! We can customize any solution to fit your requirements.
