SK-512 SD H.264 CVBS wireless video transmitter module for UAV system （can customized low latency version）
SK-512 SD H.264 CVBS wireless video transmitter module for UAV system （can customized low latency version）
Specifications
Brand Name :
Huanuo
Model Number :
SK-512
Place of Origin :
China
MOQ :
1 set
Payment Terms :
T/T,Western Union
Supply Ability :
500 pieces per month
Delivery Time :
3~5days
Packaging Details :
Carton box
Carton Box :
0.5kg
 Video input :
CVBS
Audio channel :
2 channel
Bandwidth :
2/4/8MHz
Constellation :
QPSK,QAM16,QAM64
 Output power :
0dBm(can be customized)
Encryption :
dynamic 128 bit AES
Video encoding :
H.264/MPEG2
 Modulation   :
COFDM 2K
Guard Interval :
1/32,1/16,1/8,1/4
FEC :
1/2,2/3,3/4,5/6,7/8
Description

SK-512AV COFDM video transmitter module

Product description:

SK-512AV COFDM wireless video transmitter module,adopted

advanced composite NTSC/PAL video pre-processing technology and

and efficient video encoding algorithm, improve the encoding efficiency,reduce the encoding time delay,The algorithm is optimized

and the bit error rate is improved and the quality of the image is further improved. The best image compression effect can be achieved at the lowest bit rate.

Product features:

l Using COFDM modulation technology

l Support non-standard 128 bit AES encryption

l Support digital panel operation and display, easy to use

l Highly integrated modular design, small size, stable performance

Technical characteristics

Model SK-512AV
Voltage DC 6~15V
Current 420mA-12V
Video input CVBS
Audio Channel 2 channel
Bandwidth 2/4/8MHz
Radio Frequency 300MH~860MHz stepping in 1MHz(other frequencies on request)
RF Output Power 0dBm(can be customized)
RF interface SMA
Encryption dynamic 128 bit AES encryption
FEC 1/2,2/3,3/4,5/6,7/8
Guard Interval 1/32,1/16,1/8,1/4
Carriers 2K
Encoding MPEG-2
Modulation COFDM
Constellation QPSK,QAM16,QAM64
Parameter control mode Through OLED display panel to setting the relevant parameters
Dimensions 70mm*45mm
Bolt hole spacing 58mm*41mm

SK-320 Technology parameters:

Model SK-320
Voltage DC6V～15V
Current 250mA_12V
Receiving sensitivity -104dBm/2MHz
Video output CVBS:Support SDI analog output
HDMI:Support HD1080P,720P,576,480
Bandwidth 2/2.5/4/8MHz
Radio frequency 300～860MHz(Stepping 1MHz,adjustable)
Decryption AES
Demodulation COFDM
Decoding H.264/MPEG-2
Parameter control method Through the control panel to set the relevant parameters
Audio and video output interface 2.54 port
RF singal input interface SMA,high performance dual channel diversity reception
