5.8G Long Range Wireless Ethernet Bridge 15-20km Digital MIMO with External Antenna
5.8G Long Range Wireless Ethernet Bridge 15-20km Digital MIMO with External Antenna
Specifications
Model Number :
ST58T8G-N
Place of Origin :
Shenzhen, China
Brand Name :
SUNTOR
Certification :
FCC, CE, RoHS
MOQ :
1 set
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
1000 set/ month
modulation :
OFDM
Frequency range :
5150~5825MHz
RF power :
Up to 29 ± 2 dBm
transmission range :
10-20KM (LOS)
Wireless mode :
PTP and PTMP
Standards Compliance :
IEEE 802.11a/n; IEEE802.3; IEEE802.3u
Antenna type :
External antenna
net weight :
2.25kg
Price :
Negotiation
Packaging Details :
Plastic Box
Delivery Time :
7-15 days
Description

5.8G Long Range 15-20km Digital MIMO Wireless Internet Data Bridge with External Antenna

ST58T8G-N digital wireless bridge is long range outdoor wireless bridge, working frequency is 5GHz. With long transmission distance, can avoid unnecessary the roam among the access point. It assures the stability of wireless connection and decease the products quantity.

Main features:

  • ST58T8G-N support 802.11an work mode, belonging to the industrial grade outdoor wireless bridge, dual antenna design, the maximum support 300Mbps transfer rate.

  • Design transmission distance of 10-20 kilometers.

  • Support the transmission of multimedia signals.

  • Support the Spanning Tree Protocol.

  • Support bandwidth control, up to 8 multipoint, you can write eight different MAC address.

  • Support WIFI wireless transmission, can connect Mobil phone and PC.

  • Support AP mode, bridge mode, client mode and repeater mode is very easy to use.

  • This product of good choice among the engineering, the signal is very stable.

  • Metal case 5.8GHz long range 10km durable wireless transmitter and receiver with external antenna


Parameters

Standards Compliance

IEEE 802.11a/n; IEEE802.3; IEEE802.3u

CMOS chip

Atheros AR7240+ AR9280

SDRAM

32 M Byte

Flash

8 M Byte

Network interface

2 x 10/100 Base-T RJ45 interface

Radio Frequency Type

OFDM


Transmission Rate

- 802.11a: 54, 48, 36, 24, 18, 12, 9, 6Mbps
- 802.11n:
20-MHz bandwidth: MCS 0~15 support data rate
40-MHz bandwidth: MCS 0~15 support data rate

Frequency

5.15~5.35 GHz
5.47~5.7 GHz
5.745~5.825 GHz

Transmission Power

Up to 29 ± 2 dBm

Sensitivity

-92dBm @ 11Mbps, -73dBm @ 54Mbps, -73/-69dBm @ HT20/HT40 MCS15


Security Systems

- 64-bit/128-bit/152-bit WEP encryption
- WPA/ WPA2 (-PSK using TKIP or AES) WPA/ WPA2 (-EAP using TKIP);
- 802.1x Authenticator; Hide SSID in beacons

Antenna Type

External dual antenna type


Operation mode

Operation Mode – AP/ Client Bridge/ WDS Bridge PtP and PtMP (up to 8 links)
Channel Selection (Setting varies by Country)
Transmit power adjustable stepper 1dBm

5.8G Long Range Wireless Ethernet Bridge 15-20km Digital MIMO with External Antenna
5.8G Long Range Wireless Ethernet Bridge 15-20km Digital MIMO with External Antenna
