CD100NMT with AES128 Security Protected COFDM Transmitter for UAVs and Drones
CD100NMT with AES128 Security Protected COFDM Transmitter for UAVs and Drones
CD100NMT with AES128 Security Protected COFDM Transmitter for UAVs and Drones
CD100NMT with AES128 Security Protected COFDM Transmitter for UAVs and Drones
CD100NMT with AES128 Security Protected COFDM Transmitter for UAVs and Drones
CD100NMT with AES128 Security Protected COFDM Transmitter for UAVs and Drones
Specifications
Brand Name :
SUNTOR
Model Number :
CD100NMT-V3
Place of Origin :
Shenzhen, China
MOQ :
1 set
Payment Terms :
T/T, Western Union, Paypal
Supply Ability :
1000 Set / Month
Packaging Details :
Carton
Technology :
TDD-OFDM / MIMO / 1T2R
Modulation :
QPSK / 16QAM / 64QAM
Data Rate :
24Mbps @ 10MHz (Peak)
Frequency Range :
1.4G / 2.4GHz selectable
Bandwidth :
5MHz / 10MHz / 20MHz
Power :
DC12V Power Supply
Description

CD100NMT with AES128 Security Protected COFDM Transmitter for UAVs and Drones

1. Introduction

The CD100NMT-V3 standard version device can realize long-distance two-way wireless video, audio, and data transmission. When used with the standard version of the sky terminal, the maximum air-to-ground transmission distance can reach more than 100km. The communication method can meet point-to-point two-way communication, and can also realize point-to-multipoint star networking communication.


The device provides multiple service interfaces, including 1 Ethernet port and 1 transparent serial port. It has the characteristics of small size, light weight, easy installation, and easy use. It is very suitable for wireless data transmission scenarios such as unmanned aircraft, unmanned ships, unmanned vehicles, robots, etc. At the same time, the interface form can be customized according to requirements.

2. Feature

  • 251 Grams Weight
  • Point to Multi-Point Mode
  • Dual Antenna MIMO Design
  • Up to 24Mbps Data Rate
  • 1.4G / 2.4GHz Frequency Range Optional
  • AES128 Security Protection
  • 100KM Air-to-Ground Transmission Distance

3. Specification

Wireless
Technology TDD-OFDM/MIMO/1T2R
Modulation BPSK/QPSK/16QAM/64QAM
Data Rate 24Mbps@10MHz(Peak)
Frequency Range 1428~1448MHz(Standard)
2410~2480(Optional)
810~820Mhz(Optional)
Bandwidth 5MHz/10MHz/20MHz
TX Power 5W

System
Serial Port 1 RS232
Ethernet Port 1 Ethernet Port
Security AES128 Encryption
Power DC12V Power Supply ≤30W @ DC12V Power Consumption(Air)

Interface
RF Antenna SMA×2
Serial Port Interface JST×1
Ethernet Interface JST×1
Config Interface JST×1
USB Interface JST×1
Power Input JST×1

Physical
Dimension 120x82x40mm(Air)
Weight 251g(Air)+1000g(Ground)

4. Diagram

CD100NMT with AES128 Security Protected COFDM Transmitter for UAVs and Drones

5. Accessories

CD100NMT with AES128 Security Protected COFDM Transmitter for UAVs and Drones
