20km Long Range Digital Wireless Video Transmitter and Receiver with Low Latency

Real-time mbile wireless av transmitter Description:

DS-HDT20WG is a powerful COFDM wireless video audio transmitter designed from Ding Shen Technology, it's adopts the latest COFDM modulation and narrow bandwidth at its core, which is enable to transmit 1080P/I full HD video quality in fast moving and NLOS (non-line-of-sight) environment.

With 20 watt high RF power, DS-HDT20WG can easily to transmit 10~15km NLOS long distance wireless video and 1920*1080P high definition broadcast quality image in urban area; and 100km LOS from air to ground.

The frequency, RF power, video input, and the housing of the DS-HDT20WG cofdm video transmitter all can be designed and customized based on user's application and requirement.

Parameters:

Modulation CODFM
DC input DC12V-DC14V
Working Current ≤4.7A@DC12V
Constellation QPSK,16QAM,64QAM (optional)
FEC 1/2,2/3,3/4,5/6,7/8 (optional)
Carrier 2K
Guard Interval 1/32,1/16,1/8,1/4 (optional)
Frequency 300MHz-900MHz; 1GHz-2.7GHz customized (50Mhz per interval as a frequency band)
RF power output 5-20W (adjustable)
Encryption AES128 bits user-defined password
A/V interface RCA
RF interface N type
Flatness ≤2dB(within full frequency range), ≤0.5dB(within 8MHz)
Video Harmonic 1Vp-p @ 75Ω, NTSC/PAL adaptive
CBER <2.0E-4
Video Compression H.265/H.264/MPEG-4
Resolution 1080P/720P
Video Rate 6Mbps
Work environment -30~70°
Dimension 220*140*80MM
Weight 2.3kg

Feature:

  • COFDM modulation, Stable transmission

  • H.265/H.264 video compression, DVD video quality

  • Strong casing with built-in two cooling fans

  • Mobile and NLOS video audio transmission

  • Great security by encryption of AES 128/256 bits

  • Low system latency

  • Modular design, compact structure, OEM design

  • Can be customized to add additional features, such as HDM-I/HD-SDI, data port, Ehernet and etc..20km Long Range Digital Wireless Video Transmitter And Receiver With Low Latency20km Long Range Digital Wireless Video Transmitter And Receiver With Low Latency20km Long Range Digital Wireless Video Transmitter And Receiver With Low Latency
