60W Portable Digital Wireless Audio Video Transmitter Receiver For Military Surveillance Equipment
60W Portable Digital Wireless Audio Video Transmitter Receiver For Military Surveillance Equipment
60W Portable Digital Wireless Audio Video Transmitter Receiver For Military Surveillance Equipment
60W Portable Digital Wireless Audio Video Transmitter Receiver For Military Surveillance Equipment
60W Portable Digital Wireless Audio Video Transmitter Receiver For Military Surveillance Equipment
60W Portable Digital Wireless Audio Video Transmitter Receiver For Military Surveillance Equipment
Specifications
Brand Name :
Ding Shen
Model Number :
DS-CM60H
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
1000PCS per month
Delivery Time :
3-7 days
Packaging Details :
export standard packing
Place of Origin: :
Guangdong, China
Frequency/AV: :
300-900Mhz option or 1.2Ghz; 2.4Ghz; 5.8Ghz
Modulation: :
COFDM 2K QPSK
Voltage: :
DC11-14.5V
Video rate: :
15Mbps(MAX)
Current: :
4.7A
Description

AV Link Microwave Long Range NLOS Radio COFDM Video Transmitter

AV Link Microwave Long Range NLOS Radio COFDM Video Transmitter is a portable broadcast cofdm wireless video transmitter.

AV Link Microwave Long Range NLOS Radio COFDM Video Transmitter transmits good resolution image, acts as video walkie-talkie system, adopts COFDM modulation.

AV Link Microwave Long Range NLOS Radio COFDM Video Transmitter has well safety, and this video transmitter is encrypted with AES128 bit, AES 256 bit.

AV Link Microwave Long Range NLOS Radio COFDM Video Transmitter has conventional modulation techniques, and it overcomes the reflection and coverage.

AV Link Microwave Long Range NLOS Radio COFDM Video Transmitter has better anti-jamming capacity than transmission multipath simulation technique.

AV Link Microwave Long Range NLOS Radio COFDM Video Transmitter is suitable for army training, fire rescue, marine remote control security application for its nearly live transmission high-speed mobile images and high quality image in NLOS or complicated working conditions

Warranty

  1. Twelve months free warranty for equipment
  2. Three months for components
  3. Replacement parts will be charged after one year

Specification:

Frequency/AV 300-900Mhz option or 1.2Ghz; 2.4Ghz; 5.8Ghz
Frequency/DATA 433Mhz
Modulation COFDM 2K QPSK
RF power output 60-80W (adjustable)
Voltage DC11-14.5V
Current 4.7A
Video rate 15Mbps(MAX)
Constellation QPSK,16QAM,64QAM(optional),
QPSK/16QAM/64QAM @ 6/7/8MHz
FEC 1/2,2/3,3/4,5/6, 7/8 (optional)
Guard Interval 1/32,1/16,1/8,1/4 (optional)
Bandwidth 2/2.5/4/8M(adjustable)
Video Interface HDMI;SDI; CVBS
Encryption AES 128 bit / ALLTECH Basic scrambling
Flatness Full band≤2dB ,8MHz≤0.5dB
Carrier 2K,8K
SHG >52dBc
Video Signal 1Vp-p@75Ω,NTSC/PAL adaptive
CBER <2.0E-4
Video Compression H.265/H.264
Resolution 1280*720P / 1980*1080P
Video Input 1Vp-p@75Ω,NTSC/PAL (autoadaptation)
RF Interface N(type)
Video decoding ISO/IEC13818-2 MPEG-2MP@ML
OperatingTemperature -25℃~55℃
Storage Temperature -40℃~70℃
Size 430*420*89mm
Weight 12kg

Features:

◊COFDM modulation, Stable transmission
◊H.264 video compression, DVD video quality
◊Military aluminum housing ,Strong casing with built-in two cooling fans
◊Mobile and NLOS(Non line-of-sight) transmission
◊Great security by encryption of AES 128 bits
◊Low system latency
◊Modular design, compact structure, OEM design
◊Several wavebands available: VHF/L/ S
◊ Support two-way voice communication (option).
