2 Channel Cofdm Receiver Module CVBS Long Range SD Video Transmitter
2 Channel Cofdm Receiver Module CVBS Long Range SD Video Transmitter
Specifications
Brand Name :
Ding Shen
Model Number :
DS-220T
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
1000PCS per month
Delivery Time :
3-7 days
Packaging Details :
export standard packing
DC Input: :
DC 12
Audio Channel: :
2 Channel
Operating Frequency: :
300～2400MHz,stepping 1MHz
Video Encoding: :
H.264
Video Input: :
CVBS
Channel Bandwidth: :
2.0/4.0/8.0MHz
Output Power: :
32dBm
Description

H.264 cofdm video transmitter non line of sight long range SD video transmitter

Product introduction

DS-220T Low-Delay COFDM Wireless Image Transmission Transmitter, which adopts composite NTSC/PAL video preprocessing technology and efficient video coding algorithm to improve coding efficiency, reduce coding delay, algorithm optimization,anti-error rate and further improve the image quality, and the best image compression effect can be achieved at the lowest bit rate.

Key Features

●Supports high-definition analog video NTSC/PAL input

●Adopt COFDM modulation technology, MPEG-2 image compression processing

●Highly integrated modular design, small size

●Support NLOS high speed mobile transmission

●Full aluminum alloy design, good heat dissipation

Technical Specification

Model DS-220T
Input voltage DC 12~15V
Working Current 2A_12V
Video input CVBS:480i/576i
Audio channel 2 channel
Working bandwidth 2.0/4.0/8.0MHz
Operating frequency 300～2400MHz,stepping 1MHz
Output power 32dBm
RF interface N type
video encoding H.264
Modulation COFDM
Constellation QPSK
Parameter control method Set related parameters through LED digital tube
Dimension 158mm*100mm*52mm
