CVBS Input 2 Watt RF COFDM HD Video Transmitter With 1080P 60FPS
CVBS Input 2 Watt RF COFDM HD Video Transmitter With 1080P 60FPS
CVBS Input 2 Watt RF COFDM HD Video Transmitter With 1080P 60FPS
CVBS Input 2 Watt RF COFDM HD Video Transmitter With 1080P 60FPS
Specifications
Brand Name :
Ding Shen
Model Number :
DS-HDT2W-1
Place of Origin :
China
MOQ :
1set
Price :
Negotiaiton
Payment Terms :
T/T
Supply Ability :
1,000pcs per month
Delivery Time :
3-7 days
Packaging Details :
export standard packing
Modulation: :
COFDM
Encryption: :
AES128/256bits
Dimension: :
132*90*26mm
RF Power: :
1-2W Adjustable
Video Input: :
CVBS/HDM-I
Weight: :
420g
Description

HD AV 60 KM Data Entry Anti Signal New Splitter Tactical Backpack Transmitter BNC Connector Self Defense For UAV /Drone

Such new design 1080P HD transmitter is a powerful HD transmit system,using the core of mobile communication technology COFDM(multi-carrier modulation technique),which can transmit good quality and stable full-hd digital video signal under the condition of high speed mobile and heavy building blocks transmission in city environment.Support full HD 1080P H.264 encoding format and SDI two HD inputs(single selection) as well support stereo balance audio input and narrowband transmission system.

Robot Transmitter Features:

  1. COFDM modulation;
  2. Low delay, lightweight, live broadcast;
  3. Support Full-HD quality image;
  4. Support 1080i/1080P HD transission;
  5. Built-in with HDM-I or HD-SDI interface(single selection);
  6. Support composite standard video and balanced audio input;
  7. All parameters can be adjusted by user;

Specification:

Voltage DC11V~DC16V
Current ≤1.1A/DC12.5V

Video Input

 AV: 3.5mm port, connect to standard resolution analog video signal
HDM-I/CVBS: support HD1080P,720P,576,480;
Frequency 300mHz-4400mHz (optional)
Bandwidth 2/2.5/4/8MHz(adjustable)
Output power 2 watt (adjustable)
Data encryption AES 128bit (user-defined password)
Modulation COFDM
FEC 1/2, 2/3, 3/4, 7/8
Guard Interval 1/32, 1/16, 1/8, 1/4
Video Compression H.264/MPEG-4
Standard Video Format PAL/NTSC (auto adaptation)
Parameter control method Set the related parameters through the control panel
RF Interface SMA
Working temperature -20℃~75℃
Transmission distance 1-40km max LOS (on air); 1-2km on ground station
Dimension 132*90*26mm
Weight 420g

CVBS Input 2 Watt RF COFDM HD Video Transmitter With 1080P 60FPSCVBS Input 2 Watt RF COFDM HD Video Transmitter With 1080P 60FPSCVBS Input 2 Watt RF COFDM HD Video Transmitter With 1080P 60FPSCVBS Input 2 Watt RF COFDM HD Video Transmitter With 1080P 60FPSCVBS Input 2 Watt RF COFDM HD Video Transmitter With 1080P 60FPS
