Lightweight UAV Wireless HD Video Transmitter No Delay 2MHz 3MHz 8MHz
Lightweight UAV Wireless HD Video Transmitter No Delay 2MHz 3MHz 8MHz
Lightweight UAV Wireless HD Video Transmitter No Delay 2MHz 3MHz 8MHz
Lightweight UAV Wireless HD Video Transmitter No Delay 2MHz 3MHz 8MHz
Lightweight UAV Wireless HD Video Transmitter No Delay 2MHz 3MHz 8MHz
Lightweight UAV Wireless HD Video Transmitter No Delay 2MHz 3MHz 8MHz
Specifications
Brand Name :
Ding Shen
Model Number :
DS-HDT1W
Place of Origin :
Guang Dong China
MOQ :
1set
Price :
>=1 Sets $3700
Payment Terms :
T/T
Supply Ability :
1000pcs/month
Delivery Time :
3-7 working days
Packaging Details :
72*98*32mm
Certification :
CE/FCC
Place of Origin: :
Guangdong,china
Frequency: :
300-900Mhz or other frequency customized
Consumption :
<40W
Modulation: :
COFDM
Bandwidth :
2/3/4/6/7/8MHz (option)
Description

Lightweight COFDM UAV Video Transmitter with Battery 20km LOS Lightweight from air to ground

Transmitter parameter:

Features:

1.Support FULL Hd high quality video encoding transmission(can up to H.264 High Profile 1080P@60fps,compatible with 1080 I resolution )

2.Broadcasting HD encoding compression (H.264/Level 4 standard),support 1080i/1080P HD transission.

3.COFDM modulation,Video compression code stream bandwidth can up to 12Mbps;

4.Built-in with HD-MI and HD-SDI interfaces(single selection),

5.Support composite standard video interface and balanced audio input;

6.RF bandwidth 4/8MHz(support adjusted by user),the working frequency will be displayed on the LCD;

7.It will be HD1080i transmission when the RF bandwidth is 4/8MHz.;

Frequency 300-900Mhz or other frequency customized
Modulation COFDM
Consumption <40W
Encryption AES 128 bits
Constellation QPSK(4QAM),16QAM,64QAM
FEC 1/2 2/3 3/4 5/6 7/8
Guard Interval 1/32 1/16 1/8 1/4
Carrier 2K,8K
Bandwidth 2/3/4/6/7/8MHz (option)
Transfer rate 6Mbit@8M; 2.5Mbit@4M; 1.2Mbit@2M
RF power 1 watt
Video input HDMI
Video coding MPEG-4/H.264
Video resolution 1920*1080P/I@60fps; 1280*720P/I@60fps; 704*576 PAL
Working voltage DC12V
Working Temperature -20℃ -- +55℃
Dimension 72*98*32mm
Weight 190g without battery; 250g with battery
Box colour Black
Antenna port N type
