8 Channels Portable FPV Ground Station Wireless Video Audio Receiver
8 Channels Portable FPV Ground Station Wireless Video Audio Receiver
8 Channels Portable FPV Ground Station Wireless Video Audio Receiver
8 Channels Portable FPV Ground Station Wireless Video Audio Receiver
8 Channels Portable FPV Ground Station Wireless Video Audio Receiver
8 Channels Portable FPV Ground Station Wireless Video Audio Receiver
Specifications
Brand Name :
Ding Shen
Model Number :
DS-WR968H
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
1000PCS per month
Delivery Time :
3-7 days
Packaging Details :
export standard packing
Number Of Channels: :
8 Channels
TV System: :
NTSC / PAL
Display: :
5 Inch LCD
Receiving Distance: :
100m
Output Voltage: :
3.6-4.2 V
Weight: :
205g
Description

Portable FPV Ground Station 8 Channels Wireless Video Audio Receiver

DS-WR968H is a new generation portable mini DVR developed by our company.It supports both wireless and wired cameras. Not only this, it adds new function of photo, motion detect, loop recording, power saving (auto shutdown, auto off-screen), etc.

This DVR is the ideal choice for security & protection, evidence & investigation, like police, household, sports, automotive industry, shops, etc.At the same time, with its stylish and high-end appearance, it also becomes the fashion choice of leisure goods.

Supports wireless & wired camera; photo function; motion detect recording; cycle recording; support memory up to 32G card.

8 Channels Portable FPV Ground Station Wireless Video Audio Receiver8 Channels Portable FPV Ground Station Wireless Video Audio Receiver8 Channels Portable FPV Ground Station Wireless Video Audio Receiver

Feature:


8 Channels Portable FPV Ground Station Wireless Video Audio Receiver Mini size and portable recorder with fashionable & new design;
8 Channels Portable FPV Ground Station Wireless Video Audio Receiver 5-inch super large HD screen (800X480pix), which provides clear and smooth image;
8 Channels Portable FPV Ground Station Wireless Video Audio Receiver Built-in 3200mAh high capacity Li-battery provides super long recording time up to 9.5 hours;
8 Channels Portable FPV Ground Station Wireless Video Audio Receiver Supports storage up to 32G TF card, which records up to 32 hours;
8 Channels Portable FPV Ground Station Wireless Video Audio Receiver Supports 2.4GHz & 5.8GHz wireless frequency;
8 Channels Portable FPV Ground Station Wireless Video Audio Receiver 8 channels auto/manual switch;
8 Channels Portable FPV Ground Station Wireless Video Audio Receiver It’s of high compatibility, which supports almost all computer operating system, including MAC;
8 Channels Portable FPV Ground Station Wireless Video Audio Receiver Supports multi-language.

Specifications:

Items Value
Wireless Receiving
( Choose 1 group of frequency from 2.4G/within 5.8G/beyond 5.8G)
 2.4GHz –8 channels
CH1: 2414MHz; CH2: 2432MHz; CH3: 2450MHz; CH4: 2468MHz.
CH5: 2490MHz; CH6: 2510MHz; CH7: 2390MHz; CH8: 2370MHz
Within 5.8G—8 channels
CH1: 5865MHz; CH2: 5845MHz; CH3: 5825MHz; CH4: 5805MHz.
CH5: 5785MHz; CH6: 5765MHz; CH7: 5745MHz; CH8: 5725MHz
Beyond 5.8G—8 channels
CH1: 5705MHz; CH2: 5685MHz; CH3: 5665MHz; CH4: 5645MHz.
CH5: 5885MHz; CH6: 5905MHz; CH7: 5925MHz; CH8: 5945MHz
Sensitivity -92dB
Receiving distance 100 meters
AV IN TV system NTSC / PAL
Output voltage 3.6-4.2 V
HD 5-inch LCD screen Active area 108mm(W) X 64.8mm(H)
Resolution 800 X 480 Pixel
Luminance for LCM 200 cd/m2
Cape clear 5-inch LCD screen Active area 118mm(W) X 62.8mm(H)
Resolution 480 X 272 Pixel
Luminance for LCM) 300cd/m2
Video Resolution 720*576 / 640*480
Video compress MPEG-AVI 30fps
Play format MPEG-AVI
Audio Frequency 20HZ-20KHz stereo
Earphone Output Left: 20MW+ right 20mW [16O](suit to largest volume)
Speaker 1W
Photo Format JPG/JPEG
Storage External SD card TF card 1GB-32GB (optional)
32GB recording time 10-32 hours
1GB photos 15625pcs
Operating system PC Windows & Mac OS
Port USB 2.0
Language Multiple
Power Voltage DC 5V
Current (receiving mode) 660MA
Current (recording mode) 680MA
Current (recording with off-screen mode 340MA
AC adapter DC 5V 2A
Built-in battery Li-battery 3200mAh
Standby time Wireless record ≥9.5 hours(off-screen); ≥5hours(on-screen)
Wired record ≥12 hous(off-screen); ≥6hours(on-screen) *LED camera not included.
Size (L x W x H) 131mm x 86mm x 18mm
Weight(g) 205g
