Specifications
Place of Origin :
Made in China
Brand Name :
Vespolari Jiangsu
Certification :
ISO SGS ROHS
MOQ :
1Ton
Price :
Negotiable
Payment Terms :
TT L/C
Supply Ability :
10000000per month
Packaging Details :
standard waterproof package
Delivery Time :
7-14 business days
Thickness :
3-120mm
Martensite-Ferritic :
Ss 405 , 409, 409L, 410, 420, 420J1 , 420J2 , 420F , 430 ,431...
Surface Finish :
No. 1, No. 4, No. 8, HL, 2B, BA
Standard :
ASTM, JIS, DIN, AISI, KS, EN
OEM :
YES
Name :
Carbon Seamless Steel Pipe
Description

304 Stainless Steel Pipe

Stainless steel pipe is a kind of hollow long round steel, square steel and rectangular steel, which is widely used in petroleum, chemical industry, medical treatment, food, light industry, mechanical instrument and other industrial pipelines and mechanical structural components.
Product Features
Specifications of Stainless Steel Pipe
Standard ASTM, JIS, DIN, AISI, KS, EN...
Martensite-Ferritic Ss 405 , 409, 409L, 410, 420, 420J1 , 420J2 , 420F , 430 ,431...
Austenite Cr-Ni -Mn 201, 202...
Austenite Cr-Ni 304, 304L, 309S, 310S...
Austenite Cr-Ni -Mo 316, 316L...
Super Austenitic 904L, 220 , 253MA, 254SMO, 654MO
Duplex S32304 , S32550 ,S31803 ,S32750
Austenitic 1.4372 ,1.4373, 1.4310, 1.4305, 1.4301, 1.4306 , 1.4318 ,1.4335, 1.4833 , 1.4835 , 1.4845, 1.4841, 1.4401 , 1.4404 , 1.4571 ,1.4438, 1.4541 , 1.4878 , 1.4550 , 1.4539 , 1.4563 , 1.4547
Duplex 1.4462 , 1.4362 ,1.4410 , 1.4507
Ferritic 1.4512, 1.400 , 1.4016 ,1.4113 , 1.4510 ,1.4512, 1.4526 ,1.4521 , 1.4530 , 1.4749 ,1.4057
Martensitic 1.4006 , 1.4021 ,1.4418 ,S165M ,S135M
Surface Finish No. 1, No. 4, No. 8, HL, 2B, BA, Mirror...
Specification Thickness 0.25-8mm
Outer Diameter 10-1219mm
Payment Term T/T, L/C
Package Export standard package or as your requirements
Deliver Time 7-10 working days
MOQ 1 Ton

Size of Stainless Steel Pipe
DN NPS OD(MM) SCH5S SCH10S SCH40S STD SCH40 SCH80 XS SCH80S SCH160 XXS
6 1/8 10.30 - 1.24 1.73 1.73 1.73 2.41 2.41 2.41 - -
8 1/4 13.70 - 1.65 2.24 2.24 2.24 3.02 3.02 3.02 - -
10 3/8 17.10 - 1.65 2.31 2.31 2.31 3.20 3.20 3.20 - -
15 1/2 21.30 1.65 2.11 2.77 2.77 2.77 3.73 3.73 3.73 4.78 7.47
20 3/4 26.70 1.65 2.11 2.87 2.87 2.87 3.91 3.91 3.91 5.56 7.82
25 1 33.40 1.65 2.77 3.38 3.38 3.38 4.55 4.55 4.55 6.35 9.09
32 1 1/4 42.20 1.65 2.77 3.56 3.56 3.56 4.85 4.85 4.85 6.35 9.70
40 1 1/2 48.30 1.65 2.77 3.56 3.56 3.56 4.85 4.85 4.85 6.35 9.70
50 2 60.30 1.65 2.77 3.91 3.91 3.91 5.54 5.54 5.54 8.74 11.07
65 2 1/2 73 2.11 3.05 5.16 5.16 5.16 7.01 7.01 7.01 9.53 14.02
80 3 88.90 2.11 3.05 5.49 5.49 5.49 7.62 7.62 7.62 11.13 15.24
90 3 1/2 101.60 2.11 3.05 5.74 5.74 5.74 8.08 8.08 8.08 - -
100 4 114.30 2.11 3.05 6.02 6.02 6.02 8.56 8.56 8.56 13.49 17.12
125 5 141.30 2.77 3.40 6.55 6.55 6.55 9.53 9.53 9.53 15.88 19.05
150 6 168.30 2.77 3.4 7.11 7.11 7.11 10.97 10.97 10.97 18.26 21.95
200 8 219.10 2.77 3.76 8.18 8.18 8.18 12.70 12.70 12.70 23.01 22.23
250 10 273.10 3.40 4.19 9.27 9.27 9.27 15.09 12.70 12.70 28.58 25.40

Chemical Properties of Frequently-used Austenitic Stainless Steel Material Grade
ASTM UNS EN JIS C% Mn% P% S% Si% Cr% Ni% Mo%
201 S20100 1.4372 SUS201 ≤0.15 5.5-7.5 ≤0.06 ≤0.03 ≤1.00 16.00-18.00 3.5-5.5 -
202 S20200 1.4373 SUS202 ≤0.15 7.5-10.0 ≤0.06 ≤0.03 ≤1.00 17.00-19.00 4.0-6.0 -
301 S30100 1.4319 SUS301 ≤0.15 ≤2.00 ≤0.045 ≤0.03 ≤1.00 16.00-18.00 6.0-8.0 -
304 S30400 1.4301 SUS304 ≤0.08 ≤2.00 ≤0.045 ≤0.03 ≤0.75 18.00-20.00 8.0-10.5 -
304L S30403 1.4306 SUS304L ≤0.03 ≤2.00 ≤0.045 ≤0.03 ≤0.75 18.00-20.00 8.0-12.0 -
309S S30908 1.4883 SUS309S ≤0.08 ≤2.00 ≤0.045 ≤0.03 ≤0.75 22.00-24.00 12.0-15.0 -
310S S31008 1.4845 SUS310S ≤0.08 ≤2.00 ≤0.045 ≤0.03 ≤1.50 24.00-26.00 19.0-22.0 -
316 S31600 1.4401 SUS316 ≤0.08 ≤2.00 ≤0.045 ≤0.03 ≤0.75 16.00-18.00 10.0-14.0 -
316L S31603 1.4404 SUS316L ≤0.03 ≤2.00 ≤0.045 ≤0.03 ≤0.75 16.00-18.00 10.0-14.0 2.0-3.0
317L S31703 1.4438 SUS317L ≤0.03 ≤2.00 ≤0.045 ≤0.03 ≤0.75 18.00-20.00 11.0-15.0 2.0-3.0
321 S32100 1.4541 SUS321 ≤0.08 ≤2.00 ≤0.045 ≤0.03 ≤0.75 17.00-19.00 9.0-12.0 3.0-4.0
347 S34700 1.4550 SUS347 ≤0.08 ≤2.00 ≤0.045 ≤0.03 ≤0.75 17.00-19.00 9.0-13.0 -
3-120mm Thick Carbon Seamless Steel Pipe 304 Stainless Steel Pipe OEM ODM

Packing: seaworthy wooden pallets,water proof paper,pvc film,interleaving paper, in 20' or 40' container or as per customers' requirements.
-- 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High)
-- 40ft HC:12032mm(Lengh)x2352mm(Width)x2698mm(High)

3-120mm Thick Carbon Seamless Steel Pipe 304 Stainless Steel Pipe OEM ODM

Q1:How about the shipping fees?

Shipping costs will depend upon many factors. Express will be the quickest but will be most expensive. Sea freight is ideal for large quantities, but slower. Please contact us for specific shipping quotes, which are dependent upon quantity, weight, mode and destination.

Q2:What are your prices?

Our prices are subject to change depending on supply and other market factors. We will send you an updated price list after you contact us for further information.

Q3:Do you have a minimum order quantity?

Yes, we do have minimum orders for specific international products, please contact us for more information.
