Precision Nozzle

Ruby Tipped Winding Nozzle

We manufacture the Winding Nozzle for the Coil Winding Machines. A smooth geometry

from the inside hole to the tip is required for avoiding damage to the winding wire.

Custom configurations in the designing and manufacturing of the Winding Nozzle are also

accommodated.

There is description and features about Ruby tipped coil winding nozzle as following:

Ruby tipped coil winding nozzle guides:

(Ruby Nozzles) also call wire guide tubes,wire guide eyelets,wire guide needles.It is

used on coil winding machines and cable machines for wire guide.it is made of stainless

steel and ruby by precise processing and combination.The rigidity of ruby is above than

level 9 and is just less than that of diamond.Ruby tipped coil winding nozzle guide is a

single crystal and can be made with high brightness and cleanness. It can effectively

protect paint film and ling term continual work. In using ,it with very low damage for the

enameled wire. Combined with good toughness characteristics of stainless steel,

finely processed mosaic combination, more than twice lifetime than the tungsten

carbide nozzle in the same environment using .

Key advantages of Ruby Tipped Coil Winding Nozzle:

1) High Wear Resistance

2) Scratch-Proofing

3) Straightness and Stiffness

4) Precise Exit Radii

Specification and description:

Ruby Nozzle Drawings

Size List:

Pictures Show :

Ruby Nozzle

Why do you choose us?
1.100% manufacturer
In hardware tools, the wire winding machine training industry has more than 10 years of

experience, we have more than and 100 skilled workers.
2. competitive price
One-stop service, from the material of die cutting process, production, QC, packaging,

delivery. We are sure we produce all the goods. And the quality is 100% rest assured. Many

customers are very happy to cooperate with us, because we can provide a more competitive

price as a factory.
3,The best choice of material
All of our goods are the best material from the best suppliers, whether the material is qualified

can be checked.
4. Quality Control
Before shipment, there are specialized personnel checks, each product in the packaging before

the inspection is qualified. We guarantee that each product shipment is perfect for sale.
5. Good service
We promise to answer your question in 24 hours.
