Coil Winding machine Spare Parts -Motor Nozzle

Product Features:
The product is made prcciscly of hard alloy and cnjoy the hardness up to HRA90. Two terminals

and inner hole are all receive mirror surface treatment to ensure cnameled wire makes no scrape.

Can be produced in accordance with customer requirements!

Eliminate wire insulation film damage, low friction resistance, stable wire tension.

The wire-guiding surfaces are mirror finished by diamond lapping to a surface roughness of

2 -4 micro inches Ra or better, material permit.

Superior and inferior quality of alloy wire nozzle:

1 Nozzle orifice finish:
At the junction of its location, hole and arc angle, by visual method is unable to see, only with the

high magnification magnifier to observe the side, if there is an obvious mark junction hole and

transition arc angle, then the result is brought about by it scratch the enameled wire, if the quality

of the nozzle, at the junction of the inner hole and the arc angle it is a natural excessive, no transfer

of marks.

2 In the hole:
It is the quality of the product is also very crucial in the process of product winding in the inner hole

of the enameled wire is in the mouth of the online beating state, if the internal hole grinding processing

is not good, so the scraped line and then the inevitable worth to remind is, now on the market a lot in

hole alloy wire mouth is without grinding precision or simple rough machining.
3 Hole size precision:
Precision machining line mouth, its inner hole accuracy can be controlled within 0.01mm, if the hole

size is greatly small, break phenomenon often occurs, even the winding insulation failure or interturn

short circuit is not hard to explain why.

4 Installation size precision

According to the consistency of the packing size is necessary, if it is hard to put into a small equipment fixture, it is easy to fall out of fixture and influence adjustment precision.

5 head and tail shape:
R line shape is a key part of the R mouth of the head and tail, R is too large or too small will influence

the quality of products and can withstand the tension.

Nozzle Drawings for example :

Above is just for example all size can be customized according to customer’s special dimensins drawing requirements .

Picture show :
