Tungsten Steel Pneumatic Wire Cutter For Cutting Enameled Copper Wire
Tungsten Steel Pneumatic Wire Cutter For Cutting Enameled Copper Wire
Tungsten Steel Pneumatic Wire Cutter For Cutting Enameled Copper Wire
Tungsten Steel Pneumatic Wire Cutter For Cutting Enameled Copper Wire
Tungsten Steel Pneumatic Wire Cutter For Cutting Enameled Copper Wire
Tungsten Steel Pneumatic Wire Cutter For Cutting Enameled Copper Wire
Tungsten Steel Pneumatic Wire Cutter For Cutting Enameled Copper Wire
Tungsten Steel Pneumatic Wire Cutter For Cutting Enameled Copper Wire
Specifications
Brand Name :
QIANHE
Model Number :
WIS-A
Place of Origin :
Hangzhou China
MOQ :
1 set
Price :
US$150-US$350 per set
Payment Terms :
T/T, Western Union
Supply Ability :
5000 set per month
Delivery Time :
3-7 working days
Packaging Details :
Carton /box with Foam
Materials :
Tungsten Steel
Color :
Silver
Working Pressure :
5kg/C㎡
Open mouth :
6.0mm-7.5mm
Cylinder Materials :
Alloy aluminum
Description

Tungsten Steel Straight handle Pneumatic scissors for cutting Enameled copper wire

We provides a generous selection of blades for all wire cutting needs,

including resin product gate cuts and automatic welding equipment

Air nipper standard blades for metal (Standard)

Standard type. This is a general set of blades used for cutting copper

wire and steel wire Improved durability with brazed high-speed steel

Material Special alloy steel

We offer different type of Air Nipper blades as follow:

  • Straight handle scissors (WIS Series)
  • Left curved scissors (WLS Series)
  • Right curved scissors (WLS Series)
  • Double head scissors (WIL Series)
  • Cutting and clip scissors (WCS Series)

Products features:

  1. All the blades are inlay imported tungsten steel and the using life can be sure with 100,0000 times .
  2. The Air Nipper cylinders are made of high quality alloy forged →heat treatment→finish machining →riveting technology etc;
  3. The Cylinder surface deal with hardened ,not easy to scratch ,the piston and the O-Ring are
  4. all high quality materials imported from overseas;
  5. Working Pressure :5kg/C㎡
  6. The opening is 3.8-4.2 mm ,and for special requirements it can be customized.
  7. All the Air Nipper Blades need to match with the cylinder for cutting .

Air Nipper blades drawings :

Tungsten Steel Pneumatic Wire Cutter For Cutting Enameled Copper Wire

WIS Series

Specification :

Cylinder Model Blades Model Applied cutting wire (Фmm)
Copper wire Steel Wire Soft plastic wire
CS10,C20,C40,Handheld WIS-A,WIS-B,WIS-D,WIS-F ,WIS-G,WLS/WCS/WIL 0.02-1.00 0.02-0.50 0.02-2.00
C30 WIS-A.WIS-B,WIS-C,WIS-D,WIS-F,WIS-G,WLS/WCS/WIL 0.02-1.00 0.02-0.50 0.02-2.00
C25 WIS-E 0.02-1.00 0.02-0.50 0.02-2.00
C50 WIS-E2 0.02-1.00 0.02-0.50 0.02-2.00
CS-5 ** 0.02-0.50 ** **
C45 WIB-A/B/C 0.10-2.50 0.10-1.50 0.10-3.0

Picture Show :

Tungsten Steel Pneumatic Wire Cutter For Cutting Enameled Copper Wire

WIS-A

Tungsten Steel Pneumatic Wire Cutter For Cutting Enameled Copper Wire

Matched with Air Nipper Cylinder

Tungsten Steel Pneumatic Wire Cutter For Cutting Enameled Copper Wire

Air Nipper Blades
