50hz 25mm Flying Cut Off Saw High Precision Cold Saw Cutting Machine
50hz 25mm Flying Cut Off Saw High Precision Cold Saw Cutting Machine
Specifications
Brand Name :
JCCS
Model Number :
JCCS-76-144
Place of Origin :
HeBei China
MOQ :
1 set of
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
20 Set/Sets per Month
Delivery Time :
15-30 work days
Packaging Details :
Usually a high quality steel square tube making machine is loaded in a container. Depends on the size and weight of the machine.
Product name :
Cold Cutting Flying Saw
Origin :
China
Applicable industries :
Building material stores, manufacturing plants, mechanical repair shops, construction works, energy and mining
Core components :
PLC, bearing, gear
Machine Type :
Steel pipe cold saw
Tube length :
Custom made
Dimensions (L*W*H) :
Custom made
Main selling point :
Remote control
Description

High precision metal cutting circular saw welding cutting iron pipe machine flying saw cutting machine

Introduction
"CNC Milling Cold Saw" adopts double-edge polar coordinates and two-axis motion control technology. Burr-free, low-noise, high-quality cutting. It is suitable for medium and large diameter pipes with thick wall and high strength. The same goes for square and rectangular tube cuts.

Material Q195 Q235 SPCC

Cutting range

 Round tube:MAX114mm thick:0.5～4.0mm
Square tube:MAX90×90mm thick:0.5～4.0mm
Rectangular tube:MAX 50×90mm thick:0.5～4.0mm
Production speed 80m/min(length 6 meter,dia.≤25mm)
Cutting length 1500-99999mm
Length tolerance ±1.5mm(speed diviation not more than 2%)；
Feeding direction
Operation height 800mm
Cutting burr height Max:0.25mm；
Power supply AC380V,3PH,50HZ

Features

1. Equipped with adjustable cooling spray pipeline to flush the impurities and iron filings on the saw blade and clamping block;

2. Sawing method: saw blade and feed are adjustable, that is to say, the speed of the feed servo motor is variable, and the speed of the saw blade is variable, so that the utilization rate of the saw blade is greatly improved; and the saw blade wear protection system is provided.

3. The saw blade is equipped with a steel brush device to remove iron filings on the saw blade when rotating;

50hz 25mm Flying Cut Off Saw High Precision Cold Saw Cutting Machine

Our service
1. Professional pre-sales consultation and after-sales service to help you find the best solution
2. Discuss technical details with our professional engineers
3. Strictly control the quality and production plan of the cold flying saw. You will be kept informed of any progress
4. Check the cold flying saw before shipment
5. After the warranty period, spare parts are provided at cost
6. Professional engineers help you increase production, reduce waste and reduce costs
7. Control the production progress and quality of the machine, and provide you with detailed information in time
