18hp Industrial Semi Closed Compressor Condensing Unit Condenser Refrigeration
18hp Industrial Semi Closed Compressor Condensing Unit Condenser Refrigeration
Specifications
Brand Name :
ColdLink
Model Number :
ZHBD-18U
Certification :
ISO9001 CE
Place of Origin :
Shanghai,China
MOQ :
1set
Price :
Negotiation
Payment Terms :
T/T, L/C or Negotiation
Supply Ability :
200 unit/month
Delivery Time :
20days
Packaging Details :
Wooden Packages
Applicable Industries :
Garment Shops, Building Material Shops
Compressor brand :
, Emerson
Core Components :
Compressor, Condenser, Evaporator
Horse power :
15.8 KW
Color :
Green / Black
Cooling Type :
Water Coolded Condenser
Compressor type :
Semi-hermetic piston
Feature :
Automatic Control System, Air cooled
Description

18hp Industrial Semi-closed Compressor Condensing unit Condenser Refrigeration

According to the needs of market development, our company has launched a fully enclosed box condensing unit, which changes the traditional form of fully enclosed condensing unit and can meet the needs of - 5 ℃ - 10 ℃, - 10 ℃ - 18 ℃ respectively. It can be widely used in hotels, restaurants, food, health, medicine, agriculture, chemical industry and other industries. The products of totally enclosed box condensing unit have the following characteristics:
1. The company's fully enclosed box condensing unit has a variety of protections such as phase sequence, phase loss, over current, frequent compressor startup, discharge temperature, system high and low pressure and so on.
2. It has the function of unit operation fault alarm and query. When the unit fails, the alarm sound will be sent out through the buzzer to remind the user in time.
3. The operation panel for supporting the warehouse temperature control board has the functions of temperature display, setting, defrosting control, operation parameter query, warehouse temperature alarm, etc. it is installed separately from the unit and can be installed in a place convenient for users to operate and monitor.
Features:
1. Equiped with Semi-Hermetic compressor, reliable quality; Carrier, GEA BOCK, DORIN, COPELAND brand compressors are available
2. Open type condensing unit, easy for installation and maintenance;
3. Cooling Type: Optional: Air-cooled, water cooled, evaportaing condenser;
4. Used for wide range temperature, middle and high: +5C to -5C, middle and low: -15 to -45C;
5. World famous brand parts: Danfoss, ALCO, CAREL
6. Refrigerant R404A, R22, R134a and R507 are all available.
Low Temperature Unit
Model ZHBD-9U ZHBD-12U ZHBD-14U ZHBD-18U ZHBD-23 ZHBD-28 ZHBD-34V
Power supply 　
Comp. Type 　
Horsepower 9 12 14 18 23 28 34
Model 4TES-9Y 4PES-12Y 4NES-14Y 4HE-18Y 4GE-23Y 6HE-28Y 6GE-34Y
Qty 1 1 1 1 1 1 1
Cap. & input Te-25℃ Cap (W) 9500 11700 7040 16690 19670 24600 29700
Input (KW) 6.88 8.58 5.36 12 14.27 17.69 21.8
Te-30℃ Cap (W) 6830 8550 5220 12450 14820 18340 22600
Input (KW) 5.74 7.24 4.61 10.35 12.33 15.2 18.95
Te-35℃ Cap (W) 4710 6030 3760 9000 10870 13260 16680
Input (KW) 4.64 5.94 3.89 8.75 10.46 12.75 16.19
Condenser Fan Qty 1 1 1 2 2 2 2
Fan Cap. (W) 550 550 550 460×2 460×2 550×2 780×2
pipe Gas dia. (mm) φ35 φ35 φ35 6220 7690 9170 11910
Liquid dia.(mm) φ16 φ16 φ22 7.23 8.71 10.4 13.56
Overall sizes 　 L (mm) 967 967 967 1354 1354 1870 1870
　 W (mm) 825 825 825 825 825 925 925
　 　 H(mm) 1235 1235 1235 1235 1235 1235 1235

Characteristic of condensing unit

1. Save labor ——plate work structure, well formed, light weight, saving labor

2. Save time —— connecting tube adopt bell like mouth, more convenient for connecting, can save 50% of installation time, as easy as install air conditioner

3. Mute refrigerating technology——Units’ fans are designed in a big angle, pit impressing and other mute technology

Hermetic compressor, safe & low noisy

4. Anticorrosive shell——Use anticorrosive galvanized sheet steel which experienced strict salt spray test, with additional spray coating, suitable for bad weather environment

5. Equipped with COPELAND ,, CARRIER compressors, dependable, high efficient, lower noise and little vibration

6. Equipped with check valve in inlet and outlet, easy for installation and maintain

7. Various brand of compressor for your choice

Fits different refrigerant:R134a R404 R507A R22
