75mm Freezer Insulated Walk In Cooler Cold Room Panels 100mm 120mm
75mm Freezer Insulated Walk In Cooler Cold Room Panels 100mm 120mm
Specifications
Brand Name :
Coldlink
Model Number :
50mm, 120mm, 75mm, 100mm
Certification :
ISO 9001, FM
Place of Origin :
Shanghai, China
MOQ :
10㎡
Price :
19.5
Payment Terms :
Western Union, L/C，, T/T，, D/A
Supply Ability :
2000000㎡/Year
Delivery Time :
5days
Packaging Details :
wood pallet
Panel material :
PU
Thickness :
50mm, 120mm, 75mm, 100mm
Material :
Galvanized Steel
Density :
More than 42CBM/m3
Color :
White, Grey, or Customized
Warranty :
1 Year
Application :
Chiller Room, Freezer Room, Blast Freezer Rooma
Description

50mm 75mm 100mm 120mm Camlock Insulated Walk-in Cooler Cold Storage Room Panel

Polyurethane (PU) Insulated Panels are one of the most commonly used insulation solutions in cold rooms, chillers, and freezers. Their high thermal resistance makes them a great preliminary insulation solution, especially for cold room projects that need to be assembled quickly. These panels are installed using the tongue-and-groove system as it is simple and most effective for this type of panel.

Each panel is 'foamed in place' with self-extinguishing, CFC-free polyurethane using high-pressure injection technology. This is to give a product of very low thermal conductivity of 0.020 W/m.K with high mechanical strength at low density (45kg/m3) and 95% closed cell content. Thickness is available from 50mm, 75mm, 100mm, and 120mm to 150mm for various temperatures, structures, and applications.

Panel Thickness(mm)
Stroge Temp
Stroge Product
50
5℃~ 20℃
Fruit,Vegetable
75
-5℃~ 5℃
Ice cream
100
-25℃~ -10℃
Fish,Seafood
120
-25℃~ -10℃
Fish,Seafood
150
-25℃~-45℃
Meat, Seafood quick frozen
200
below -45℃
Fresh Seafood
