High strength SUS420j1 martensitic Cold Rolled Steel Strip for mold development
High strength SUS420j1 martensitic Cold Rolled Steel Strip for mold development
High strength SUS420j1 martensitic Cold Rolled Steel Strip for mold development
High strength SUS420j1 martensitic Cold Rolled Steel Strip for mold development
High strength SUS420j1 martensitic Cold Rolled Steel Strip for mold development
High strength SUS420j1 martensitic Cold Rolled Steel Strip for mold development
High strength SUS420j1 martensitic Cold Rolled Steel Strip for mold development
High strength SUS420j1 martensitic Cold Rolled Steel Strip for mold development
Specifications
Place of Origin :
CHINA
Brand Name :
STTOY
Model Number :
400 series cold rolled steel strip
MOQ :
1 ton
Packaging Details :
Pallet(required by the customers' requirements)
Delivery Time :
20-60 working day
Payment Terms :
L/C,T/T,Paypal
Supply Ability :
100 tons
Description

High strength SUS420j1 martensitic Cold Rolled Steel Strip for mold development

SUS420j1 cold rolled stainless steel strip with thickness:0.3-1.0mm(+-0.01mm) width: 20-600mm HV160-400 Surface:2B BA

Description:

Alloy tool steel 420J1 is a martensitic stainless steel, quenched state, it has a high carbon, high strength, hardness and wear resistance, corrosion resistance is somewhat less for high mechanical performance requirements, corrosion resistancerequires the general some parts.

Applications:

Turbine blades, mold development, tool material, conventional gaskets, friction plate metal stamping industry.

Specifications:

Chemical composition:

C

Si

Cr

Mn

P

S

0.16-0.25;

≤1.00

12.00-14.00

≤1.00

≤0.040

≤0.030

N/mm2

σb (MPa)

σs (MPa)

ψ (%)

Hardness

Density

C(20℃)

Melting point

Resistivity

>=205

>=635

>=205

>=20

<=187HB,<=90HRB,<=200HV

7.93g/cm3

0.502J*(g.c)-1

1398~1420℃

0.73Ώ*mm2*m-1

Temperature℃

20

100

500

Thermal conductivity

λ/w(m*℃)-1

12.1

16.3

21.4

Temperature℃

20-200

20-200

20-300

20-400

Coefficient of linear expansionα/(10-6/℃)

16.0

16.8

17.5

18.1


Thinckness:0.3-1.0mm

Width: 20-600mm

Hardness: HV160-400

thickness Tolerance:±0.01mm

width Tolerance:±0.02mm

surface: good arc edge,bright, no scraping wire

The commom size:

0.1*160mm 0.1*300mm 0.1*140mm

0.06*200mm 0.06*300mm 0.06*400mm

0.2*20mm, 0.2*30mm 0.2*40mm

0.2*2mm 0.2*3mm 0.2*4mm

other sizes as your requirements to produce.

Density:

Steel Grade

Density(g/cm3)

201,202,301,302,303, 304,304L,305,321

7.93

316,316L,316S,347,309S,310,310S

7.98

405,410,420

7.75

409,430,434

7.7

Stainless steel theoretical weight formula:

Weight (kg) = thickness (mm) × width (mm) x length (mm) × density values

Stainless steel gravity:

Chromium stainless take 7.75 ton / M3

Chrome-nickel stainless steel take 7.93 ton / M3

Iron take 7.87 ton / M3

Competitive Advantage:

First-class quality, complete specifications, reasonable price, timely delivery and rigorous specified according to customer requirements, suited materials for basic principles, to allow customers to buy satisfaction with assured.
