2B high initial permeability soft magnetic stainless steel alloy Cold Rolled Coils
2B high initial permeability soft magnetic stainless steel alloy Cold Rolled Coils
2B high initial permeability soft magnetic stainless steel alloy Cold Rolled Coils
2B high initial permeability soft magnetic stainless steel alloy Cold Rolled Coils
2B high initial permeability soft magnetic stainless steel alloy Cold Rolled Coils
2B high initial permeability soft magnetic stainless steel alloy Cold Rolled Coils
2B high initial permeability soft magnetic stainless steel alloy Cold Rolled Coils
2B high initial permeability soft magnetic stainless steel alloy Cold Rolled Coils
Specifications
Place of Origin :
CHINA
Brand Name :
STTOY
MOQ :
1 ton
Packaging Details :
Pallet(required by the customers' requirements)
Delivery Time :
20-60 working day
Payment Terms :
L/C,T/T,Paypal
Supply Ability :
100 tons
Model Number :
Alloy cold rolled steel strip
Description

2B high initial permeability soft magnetic stainless steel alloy Cold Rolled Coils

High initial permeability soft magnetic alloy T:0.03—0.10mm W:180—250mm T:0.10—1.0mm W:10—250mm T:1.00—2.50mm W:100—250mm

Description:

Having a high or very high initial permeability and the large magnetic permeability and low coercive force, the lower the saturation magnetic induction.

Applications:

The high sensitivity and a small power transformer used in the weak magnetic field, small power transductor, relays, chokes, magnetic recording apparatus with the head, the magnetic shield, and a variety of tape wound cores, the cutting core and laminated core.

Specifications:

Thickness:0.03—0.10mm Width:180—250mm

Thickness:0.10—1.0mm Width:10—250mm

Thickness:1.00—2.50mm Width:100—250mm

Tolerance: +/-0.01mm.

Other specifications can be customized

Surface:2B

Hardness:240—280HV(As order’s requirements)

MOQ:1 tons

Port of Loading:Shanghai

Payment:T/T

Alloy

Name

Type

Level

Thickness /diameter

/mm

The agnetic permeability μ in 0.8A / m magnetic field strength

μ0.8 (mH / m)

Maximum permeability μm (mH / m)

Coercivity (saturation magnetic induction)

Hc/A·m-1

≤

Saturation magnetic induction

Bs/T

≥

1J80

Cold rolled strip

Ⅲ

0.03~0.04

30400(38)

120000(150)

1.6

0.63

0.05~0.09

40000(50)

200000(250)

1.0

0.63

0.10~0.34

44800(56)

200000(250)

1.0

0.63

0.35~0.50

50400(63)

248000(310)

0.8

0.63

Hot rolled flat

4.5~20

22000(27.5)

80000(100)

2.4

0.65

Hot forging bar

20~100

22000(27.5)

80000(100)

2.4

0.65

1J85

Cold rolled strip

Ⅰ

0.03~0.04

18000(22.5)

80000(100)

3.6

0.70

0.05~0.09

28000(35)

110000(137.5)

2.4

0.70

0.10~0.19

30000(37.5)

150000(187.5)

1.6

0.70

0.20~0.34

40000(50)

180000(225)

1.2

0.70

0.35~1.00

50000(62.5)

250000(312.5)

0.8

0.70

1.10~2.50

40000(50)

150000(187.5)

1.2

0.70

Ⅱ

0.03~0.04

30000(37.5)

110000(137.5)

2.4

0.70

0.05~0.09

40000(50)

140000(175)

1.6

0.70

0.10~0.19

50000(62.5)

180000(225)

1.2

0.70

0.20~0.34

60000(75)

200000(250)

1.0

0.70

0.35

550406(8.8)

260000(325)

0.7

0.70

Hot rolled flat

4.5~20

30000(37.5)

100000(125)

1.6

0.70

Hot forging bar

20~100

30000(37.5)

100000(125)

1.6

0.70

1J86

Cold rolled strip

0.03~0.04

30000(37.5)

110000(137.5)

2.4

0.60

0.05~0.09

40000(50)

150000(187.5)

1.4

0.60

0.10~0.19

50000(62.5)

180000(225)

1.2

0.60

0.20~0.34

60000(75)

220000(275)

0.7

0.60

0.35~1.00

50000(62.5)

200000(250)

1.2

0.60

Competitive Advantage:

First-class quality, complete specifications, reasonable price, timely delivery and rigorous specified according to customer requirements, suited materials for basic principles, to allow customers to buy satisfaction with assured.
