Specifications
Place of Origin :
CHINA
Brand Name :
STTOY
MOQ :
1 ton
Packaging Details :
Pallet(required by the customers' requirements)
Delivery Time :
20-60 working day
Payment Terms :
L/C,T/T,Paypal
Supply Ability :
100 tons
Model Number :
Alloy cold rolled steel strip
Description

1J87.1J88.1J89.1J90,1J91 0.03-0.10*180-200mm,>0.10-1.00*10-200mm Hv_240-280 Surface 2B(Or customized)

Description:

Having a high initial permeability, high resistivity, hardness, strength, abrasion resistance, magnetic on the stress is not sensitive.

Applications:

Tape recorder, video recorder, digital movie projector and computer tape drive head chip, micro motors, transformers, sensors, magnetic amplifiers and other high-frequency inductive element core.

Specifications:

Thickness:0.03—0.10mm Width:180—200mm

Thickness:>0.10-1.00mm Width:10-200mm

Tolerance: +/-0.01mm.

Other specifications can be customized

Surface:2B

Hardness:240—280HV(As order’s requirements)

MOQ:1 tons

Port of Loading:Shanghai

Payment:T/T

Magnetic properties:

Alloy name

Thickness/mm

B=0.002T μ1(mH/m)

1kHz

10kHz

100kHz

500kHz

1000kHz

>=

1J87

0.02

23040(28.8)

5440(6.80)

1000(1.25)

700(0.875)

0.03

25040(31.3)

4000(5.00)

800(1.00)

500(0.625)

0.05

26000(32.5)

1800(2.25)

400(0.50)

200(0.25)

0.10

23040(28.8)

800(1.00)

1J88

0.02

22000(27.5)

4504(5.63)

0.03

24000(30.0)

3000(3.75)

0.05

22000(27.5)

1504(5.88)

0.10

20000(25.0)

780(0.975)

1J89

0.02

12000(15.0)

5440(6.80)

1200(1.50)

800(1.00)

0.03

14000(17.5)

4000(5.00)

1000(1.25)

600(0.75)

0.05

16000(20.0)

1800(2.25)

500(0.0625)

3000(0.375)

0.10

13040(16.3)

800(1.00)

1J90

0.02

23040(28.8)

6000(7.5)

1200(1.50)

800(1.00)

0.03

25040(31.3)

4504(5.63)

904(1.13)

700(0.875)

0.05

26000(32.5)

2000(2.5)

600(0.75)

0.10

23040(28.8)

904(1.13)

1J91

0.02

3904(4.88)

3000(3.75)

1000(1.25)

700(0.875)

0.03

4000(5.00)

1504(1.88)

800(1.00)

0.05

4200(5.25)

1000(1.25)

300(0.375)

0.10

3704(4.63)

500(0.625)

Competitive Advantage:

First-class quality, complete specifications, reasonable price, timely delivery and rigorous specified according to customer requirements, suited materials for basic principles, to allow customers to buy satisfaction with assured
