JIS ASTM Cold Rolled Stainless Steel Strip For Ladder , Bridge 200mm Width Flat Steel Bar
Quick Detail:
316L cold rolled stainless steel strip
1. Commodity: 316L stainless steel sheet
2. GB: 00Cr17Ni14Mo2
3. Grade: 316L
4. Certification: ISO,SGS BV
5. Surface: No. 1, No. 2, polishing 8K, wire drawing or as requested
6. Thickness: 3.0mm to 16.0mm
7. Width: 1500mm, 1800mm, 2000mm or as required
8. Length: 2000mm-3000mm or as customers' request
9. Standard: JIS, AISI, ASTM, etc.
Description:
Stainless steel flat bar is a kind of steel which has cross section of rectangle and edge of the pure steel. It can be also the semi-finished product. There are cold-drawn polish flat bar and hot-rolled pickled flat bar. The two sides are equal. Its width is 12mm to 300 mm and thickness is 4mm to 60 mm. Stainless steel flat bar can be finished steel, also can be welded pipe billet and sheet billet. It is used in hoop iron parts, tools and machinery manufacture, vehicles, ships, construction, chemical industry, escalator. Hot-rolled steel flat bar is a kind of rectangular strip steel. Its specifications expressed as thickness and width. Hot-rolled steel flat bar can be finished steel, used for component, ladder, bridges, fences, etc. Thickness is 3mm to 60 mm, width is 10mm to 200 mm
Applications:
Restaurant equipment,
Cooking utensils sinks,
Automotive trim,
Architectural applications such as windows and doors,
Railway cars, trailers and hose clamps.
Chemical tank, pipe.
Medical equipment, Food industry, Construction material, Kitchen utensils
Building construction decoration
Electric equipment,
Specifications:
Grade | Material | C | Si | Mn | P | S | Cr | Cu | Mo | Ni |
201 | 1Cr17Mn6Ni5N | Max0.15 | Max1 | 5.5 to 7.5 | Max0.06 | Max0.03 | 16 to 18 | 3.5 to 5.5 | ||
202 | 1Cr18Mn8Ni5N | Max0.15 | Max1 | 7.5 to 10 | Max0.06 | Max0.03 | 17 to 19 | |||
304 | 0Cr18Ni9 | Max0.07 | Max1 | Max2 | Max0.045 | 0.15 to 0.35 | 17.5 to 19.5 | Max1 | 8 to 10 | |
304L | 00Cr19Ni10 | Max0.03 | Max1 | Max2 | Max0.045 | Max0.03 | 18 to 20 | 2 to 2.5 | 10 to 12 | |
309S | 0Cr23Ni13 | Max0.08 | Max1 | Max2 | Max0.045 | Max0.03 | 22 to 24 | 12 to 15 | ||
310S | 0Cr25Ni20 | Max0.08 | Max1 | Max2 | Max0.035 | Max0.03 | 24 to 26 | 19 to 22 | ||
316 | 0Cr17Ni14Mo2 | Max0.07 | Max1 | Max2 | Max0.045 | Max0.03 | 16.5 to 18.5 | 2 to 205 | 10 to 13 | |
316L | 00Cr17Ni14Mo2 | Max0.03 | Max1 | Max2 | Max0.045 | Max0.03 | 17 to 19 | 2.5 to 3 | 12.5 to 15 | |
410 | 1Cr13 | 5 | Max1 | Max0.04 | Max0.03 | 11.5 to 13.5 | ||||
420 | 2Cr13 | 0.3 to 0.4 | Max1 | Max0.1 | Max0.04 | Max0.03 | 12 to 14 | |||
430 | 1Cr17 | Max0.08 | Max1 | Max1.5 | Max0.04 | 0.03 | 12 to 14 |
These are some of its characteristics:
- Forming and welding properties
- Corrosion/ oxidation resistance thanks to the chromium content
- Deep drawing quality
- Excellent toughness, even down to cryonegic temperatures which are defined as very low temperatures
- Low temperature properties responding well to hardening by cold working
- Ease of cleaning, ease of fabrication, beauty of appearance Grade 316 is low carbon. It does not require post-weld annealing and so is extensively used in heavy gauge components (over about 6mm)
Competitive Advantage:
1) Transportation speed is quick
2) High quality, quantity is with preferential treatment
3) We can cut stainless steel sheet in any shapes as customers’ requests
4) Famous stainless steel company in China .
5) Strong ability to supply
6) Branded stainless steel
7) More than 200 patterns
8) Bottom price
9) Reliable quality and service
10) Long service life
