Silicon Steel Lamination Cut to Length Machine for Steel Strip Cutter
Silicon Steel Lamination Cut to Length Machine for Steel Strip Cutter
Silicon Steel Lamination Cut to Length Machine for Steel Strip Cutter
Silicon Steel Lamination Cut to Length Machine for Steel Strip Cutter
Silicon Steel Lamination Cut to Length Machine for Steel Strip Cutter
Silicon Steel Lamination Cut to Length Machine for Steel Strip Cutter
Silicon Steel Lamination Cut to Length Machine for Steel Strip Cutter
Silicon Steel Lamination Cut to Length Machine for Steel Strip Cutter
Silicon Steel Lamination Cut to Length Machine for Steel Strip Cutter
Silicon Steel Lamination Cut to Length Machine for Steel Strip Cutter
Silicon Steel Lamination Cut to Length Machine for Steel Strip Cutter
Silicon Steel Lamination Cut to Length Machine for Steel Strip Cutter
Specifications
Brand Name :
WKH
Model Number :
N/A
Certification :
ISO9001:2000,CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiatable
Payment Terms :
L/C, T/T, D/P
Supply Ability :
1~30 sets per month
Delivery Time :
30~180 days
Packaging Details :
Strong wooden package in accordance with buyer’s requirements
Description

Silicon Steel Lamination Cut to Length Machine for Steel Strip Cutter

Description:

The kind of steel coil cut-to length/shearing line is specifically for metal coil after uncoiling,leveling, fixed length, cutting into required length plate and stacking.It is suitable for processing of cold-rolled and hot-rolled carbon steel, silicon steel, tinplate, stainless steel and various metal materials after coated zinc on surface.steel coil cut-to-length/shearing line consists of loading car, un-coiler machine, leveling machine, feeding mechanism, cutting machine,conveying machine, stacking equipment and other components.

Applications:

1. The series steel coil cut to length line is for the metal rolling plate after coiling, leveling, fixed length, cutting into the required length flat sheet and stacking.

2. It is suitable for processing cold-rolled and hot-rolled carbon steel, silicon steel, tinplate, stainless steel and various metal materials after coated zinc on surface.

3. Cross cutting line consists of loading car, uncoiler, leveling, feeding mechanism, cutting machines, transport equipment, stacking equipment and other components.

Specifications:

Model

Sheet Thickness

(mm)

Coil Weight

(ton)

Coil Width

(mm)

Cut speed

(M/min)

Total power

(Kw)

Occupied area

(M)

CTLH-400

0.2—2.0

5 MAX

150-600

0-60

65

18X4

CTLH-600

0.2—2.0

10 MAX

200-800

0-60

90

19X4

CTLH-850

0.2—2.0

15 MAX

300-1000

0-60

150

20X4

CTLH-1300

0.2—2.0

15 MAX

300-1300

0-60

210

25X8

CTLH-1600

1.0—8.0

30 MAX

400-1550

0-60

360

30X14

CTLH-2000

4.0—12.0

35 MAX

500-1950

0-45

650

55X14
