Steel Flange, Plate flange, class 150lbs, 300lbs, 600lbs, 900lbs, 1500lbs,

Class 150 LBS Plate Flanges, 300 LBS Plate Flanges, 600 LBS Plate Flanges, 900 LBS Plate Flanges, 1500 LBS Plate Flanges

Plate Flanges Plate Flanges, which are of wide variety, are manufactured mainly from plates. They are conforming to national & international standards and they are hubless. Plate flanges are produced from quality mill plates. Before cutting pieces out of plates, each plate is checked for serious laminations. They should be virtually free of voids, non-metallic inclusions and other defects. Another important property of plate is its weldability & hardenability. For more critical application of flanges, the hardness, strength and impact properties are also important factors. These properties vary through, along and across the section of the product as a result of temperature and microstructural variations during hot rolling, cold rolling or quenching and cooling Size : 1/2"NB TO 60"NB IN

Plate Flanges Standard : AS A150, AS A300, TABLE D,E,F,H, DIN, ND-6,10, 16, 25, 40 Etc

Plate Flanges Type

• Plate Blind
• Slip On (SORF)
• Blind (BLRF)
• Lap Joint
• Reducing
• Ring Joint
• Large Dia Ring

SPECIFICATIONS AS PER THE INTERNATIONAL STANDARD ASTM, ASME, API, AISI, BS, ANSI, DIN, JIS, MSSP, NACE

Plate Flanges Materials

Nickel Alloy Plate Flanges
Standard :

• ASTM / ASME SB 162 / 127 / 424 / 168 / 443 / 574 / 462.
• UNS 10276 -HASTELLOY C 276 Plate Flanges
• UNS 2200- NICKEL 200 Plate Flanges
• UNS 2201 -NICKEL 201 Plate Flanges
• UNS 4400 - MONEL 400 Plate Flanges
• UNS 8020 -ALLOY 20 Plate Flanges
• UNS 8825 -INCONEL 825 Plate Flanges
• UNS 6600 -INCONEL 600 Plate Flanges
• UNS 6601- INCONEL 601 Plate Flanges
• UNS 6625 -INCONEL 625 Plate Flanges

Copper Alloy Plate Flanges

• C 70600 (CU -NI- 90/10) - Cupro Nickel Plate Flanges
• C 71500 (CU -NI- 70/30) - Copper Nickel Plate Flanges
• UNS NO. C 92200, UNS NO. C 83600, UNS NO. UNS NO C 10100,
• C 10200, C 10300, C 10800, C 12000, C 12200

Duplex Steel Plate Flanges
Grade : S 31803 , S 32205.

Stainless Steel Plate Flanges - SS Plate Flanges

• ASTM A182
• ASTM SA 240 .
• Grade : 304, 304L, 304H, 309S, 309H, 310S, 310H, 316, 316TI, 316H, 316L, 316LN, 317, 317L, 321, 321H, 347, 347H, 904L..

Alloy Steel Plate Flanges - AS Plate Flanges
ASTM SA 387 Grade 1/5/9/11/22/91

Carbon Steel Plate Flanges - CS Plate Flanges
ASTM A36, IS 2062

Low Temperature Carbon Steel Plate Flanges - LTCS Plate Flanges
A516 GR.70

Value Added Services for Plate Flanges

• Hot Dip Galvanizing

Test Certificate
Mill Test Certificate as per EN 10204 / 3.1B
