Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System
Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System
Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System
Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System
Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System
Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System
Specifications
Place of Origin :
China
Brand Name :
TECHWELL
Certification :
CE
Model Number :
TW-FD1250
MOQ :
1 Set
Price :
Contact Us
Packaging Details :
Standard packing
Delivery Time :
55-65 working days
Payment Terms :
40% T/T in advance, 60% T/T before shipment
Supply Ability :
20 sets
Description


Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System

Main Specifications of Floor Decking Panel Roll Forming Machine

  • Material Spec: Galvanized steel sheet
  • Thickness of Coil Sheet: 0.8 --1.2 mm
  • Main Motor Power of Floor decking roll forming machine: 18.5kw
  • Forming Speed: 10--12m/min
  • Hydraulic Station Power: 4kw
  • Quantity of Stands: About 24 groups
  • Hydraulic Pressure: 10~12Mpa
  • Controlling System: PLC
  • Index Error of Length: 10m±1.5mm
  • Total Weight: About 1800kg
  • Voltage: 380V 3 phase 50Hz or at buyers requirement

Main Components

  • Decoiler ----------------------------------------------- 1 Unit
  • Feeding ----------------------------------------------- 1 Unit
  • Main roll forming machine ----------------------------- 1 Unit
  • Hydraulic cutting device ------------------------------- 1 Unit
  • Hydraulic Station ------------------------------------- 1 Unit
  • PLC computer control -------------------------------- 1 Unit
  • Output table ----------------------------------------- 1 Unit

Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System

Reference Drawings

Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System

Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System

Application

Steel floor deck, metal deck, steel deck, metal decking sheet, steel structure floor deck...

Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System

Our Advantage

  • High Quality
  • Reliable
  • Durable
  • Reasonable Price
  • Good after Service
  • 1 Year Warranty
  • More Than 10 Years Experience

Machine Picture

Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System

Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System

Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System

Factory Pictures

Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System

Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System

Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System

Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System

Certificate

Steel Structure Floor Decking Panel Roll Forming Machine With PLC Control System
